Product comparison · 2 network switch modules

Allied Telesis AT-XEM-12Sv2 network switch module Gigabit Ethernet vs Allied Telesis AT-XEM-24T network switch module Gigabit Ethernet

14specifications compared
2differ
12identical
5known for one product only

Key differences

Ethernet LAN data rates
- AT-XEM-12Sv2 network switch module Gigabit Ethernet:100,1000 Mbit/s
- AT-XEM-24T network switch module Gigabit Ethernet:10,100,1000 Mbit/s

Side by side

Differences highlightedShow differences only

Comparison of AT-XEM-12Sv2, AT-XEM-24T
19 specifications	A Allied Telesis AT-XEM-12Sv2 network switch module Gigabit Ethernet Model AT-XEM-12Sv2 View product	B Allied Telesis AT-XEM-24T network switch module Gigabit Ethernet Model AT-XEM-24T View product
Network2 differ
Ethernet interface type	Gigabit Ethernet	Gigabit Ethernet
Ethernet LAN data ratesDiffers	100,1000 Mbit/s	10,100,1000 Mbit/s
Networking standardsDiffers	IEEE 802.3u, IEEE 802.3z	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Copper ethernet cabling technologyKnown for one	Unknown — not stated by the source	10BASE-T, 100BASE-TX, 1000BASE-T
Optical fiberidentical
Fiber optic connectorKnown for one	SFP	Unknown — not stated by the source
Ports & interfacesidentical
Fiber ports quantityKnown for one	12	Unknown — not stated by the source
I/O portsKnown for one	Unknown — not stated by the source	24 x RJ.5
Performanceidentical
Quality of Service (QoS) support	Yes	Yes
Compatibility	Allied Telesis SwitchBlade x908 / x900	Allied Telesis SwitchBlade x908 / x900
Operational conditionsidentical
Operating altitudeKnown for one	0 - 3050 m	Unknown — not stated by the source
Operating relative humidity (H-H)	5 - 80%	5 - 80%
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage relative humidity (H-H)	5 - 95%	5 - 95%
Storage temperature (T-T)	-25 - 70 °C	-25 - 70 °C
Certificatesidentical
Safety	UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1	UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1
Certification	UL, cUL, TUV RoHS	UL, cUL, TUV RoHS
Weight & dimensionsidentical
Dimensions (WxDxH)	109 x 253 x 45 mm	109 x 253 x 45 mm
Weight	820 g	820 g
Packaging dataidentical
Package weight	1.4 kg	1.4 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
