Product comparison · 2 network extenders

Zyxel WRE2206 Network transmitter & receiver White vs Zyxel WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s

25specifications compared
11differ
14identical
16known for one product only

Key differences

Data transfer rate
- WRE2206 Network transmitter & receiver White:300 Mbit/s
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:450 Mbit/s
Certification
- WRE2206 Network transmitter & receiver White:CE LVD CE, FCC
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:CE LVD, CE, FCC
AC input voltage
- WRE2206 Network transmitter & receiver White:220-230 V
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:100-240 V
Operating relative humidity (H-H)
- WRE2206 Network transmitter & receiver White:10 - 90%
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:10 - 95%
Storage relative humidity (H-H)
- WRE2206 Network transmitter & receiver White:10 - 90%
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:10 - 95%
Width
- WRE2206 Network transmitter & receiver White:55 mm
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:46.5 mm
Depth
- WRE2206 Network transmitter & receiver White:83 mm
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:62.3 mm
Height
- WRE2206 Network transmitter & receiver White:78 mm
- WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s:90.9 mm

Side by side

Differences highlightedShow differences only

Comparison of WRE2206, WRE6505
41 specifications	A Zyxel WRE2206 Network transmitter & receiver White Model WRE2206 View product	B Zyxel WRE6505 network extender Network transmitter & receiver White 10, 100 Mbit/s Model WRE6505 View product
Performance1 differ
Type	Network transmitter & receiver	Network transmitter & receiver
Data transfer rateDiffers	300 Mbit/s	450 Mbit/s
WPS push button	Yes	Yes
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100 Mbit/s
Firmware upgradeableKnown for one	Unknown — not stated by the source	Yes
Antennaidentical
Antenna gain level (max)Known for one	2 dBi	Unknown — not stated by the source
Network2 differ
Cabling technology	10/100Base-T(X)	10/100Base-T(X)
Networking standardsKnown for one	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n	Unknown — not stated by the source
Wi-Fi	Yes	Yes
Wi-Fi standardsDiffers	802.11b, 802.11g, Wi-Fi 4 (802.11n)	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)Known for one	300 Mbit/s	Unknown — not stated by the source
Security algorithmsDiffers	64-bit WEP, 152-bit WEP, WPA-PSK, WPA2-PSK	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Automatic channel selectionKnown for one	Unknown — not stated by the source	Yes
BandwidthKnown for one	Unknown — not stated by the source	5 GHz
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	1	1
Design1 differ
Product colour	White	White
Mounting type	Wall	Wall
LED indicators	Yes	Yes
On/off switch	Yes	Yes
CertificationDiffers	CE LVD CE, FCC	CE LVD, CE, FCC
Power1 differ
AC input voltageDiffers	220-230 V	100-240 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Power consumption (max)Known for one	3 W	Unknown — not stated by the source
Power consumption (typical)Known for one	Unknown — not stated by the source	3 W
Operational conditions2 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C	-30 - 70 °C
Operating relative humidity (H-H)Differs	10 - 90%	10 - 95%
Storage relative humidity (H-H)Differs	10 - 90%	10 - 95%
Weight & dimensions4 differ
WidthDiffers	55 mm	46.5 mm
DepthDiffers	83 mm	62.3 mm
HeightDiffers	78 mm	90.9 mm
WeightDiffers	68 g	98 g
Packaging contentidentical
AC adapter includedKnown for one	Yes	Unknown — not stated by the source
Cables included	LAN (RJ-45)	LAN (RJ-45)
Quick start guide	Yes	Yes
Packaging dataidentical
Package typeKnown for one	Box	Unknown — not stated by the source
Package widthKnown for one	155 mm	Unknown — not stated by the source
Package depthKnown for one	75 mm	Unknown — not stated by the source
Package heightKnown for one	135 mm	Unknown — not stated by the source
Package weightKnown for one	250 g	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	85176990	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
