Product comparison · 2 network extenders

LogiLink UA0178 network extender Network transmitter vs LogiLink WL0193 network extender Network repeater White

10specifications compared
8differ
2identical
22known for one product only

Key differences

Type
- UA0178 network extender Network transmitter:Network transmitter
- WL0193 network extender Network repeater White:Network repeater
Data transfer rate
- UA0178 network extender Network transmitter:480 Mbit/s
- WL0193 network extender Network repeater White:300 Mbit/s
Operating temperature (T-T)
- UA0178 network extender Network transmitter:0 - 55 °C
- WL0193 network extender Network repeater White:0 - 40 °C
Cables included
- UA0178 network extender Network transmitter:USB
- WL0193 network extender Network repeater White:LAN (RJ-45)
Package width
- UA0178 network extender Network transmitter:235 mm
- WL0193 network extender Network repeater White:120 mm
Package depth
- UA0178 network extender Network transmitter:201 mm
- WL0193 network extender Network repeater White:85 mm
Package height
- UA0178 network extender Network transmitter:62 mm
- WL0193 network extender Network repeater White:100 mm
Package weight
- UA0178 network extender Network transmitter:390 g
- WL0193 network extender Network repeater White:183 g

Side by side

Differences highlightedShow differences only

Comparison of UA0178, WL0193
32 specifications	A LogiLink UA0178 network extender Network transmitter Model UA0178 View product	B LogiLink WL0193 network extender Network repeater White Model WL0193 View product
Performance2 differ
TypeDiffers	Network transmitter	Network repeater
Data transfer rateDiffers	480 Mbit/s	300 Mbit/s
ChipsetKnown for one	Unknown — not stated by the source	Realtek RTL8196E + RTL8192ER
WPS push buttonKnown for one	Unknown — not stated by the source	Yes
Maximum transfer distanceKnown for one	50 m	Unknown — not stated by the source
Cable types supportedKnown for one	Cat5, Cat5e, Cat6	Unknown — not stated by the source
Antennaidentical
Antennas quantityKnown for one	Unknown — not stated by the source	2
Antenna gain level (max)Known for one	Unknown — not stated by the source	2 dBi
Networkidentical
Cabling technologyKnown for one	Unknown — not stated by the source	10/100Base-T(X)
Networking standardsKnown for one	Unknown — not stated by the source	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-FiKnown for one	Unknown — not stated by the source	Yes
Wi-Fi standardsKnown for one	Unknown — not stated by the source	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithmsKnown for one	Unknown — not stated by the source	WEP, WPA, WPA2, WPS
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	1	1
USB 2.0 ports quantityKnown for one	1	Unknown — not stated by the source
Designidentical
Product colourKnown for one	Unknown — not stated by the source	White
LED indicatorsKnown for one	Unknown — not stated by the source	Signal strength
Poweridentical
AC input voltageKnown for one	Unknown — not stated by the source	5 V
Input currentKnown for one	Unknown — not stated by the source	1 A
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 55 °C	0 - 40 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	10 - 90%
Weight & dimensionsidentical
WidthKnown for one	Unknown — not stated by the source	42 mm
DepthKnown for one	Unknown — not stated by the source	54 mm
HeightKnown for one	Unknown — not stated by the source	86 mm
WeightKnown for one	Unknown — not stated by the source	77 g
Packaging content1 differ
Cables includedDiffers	USB	LAN (RJ-45)
Manual	Yes	Yes
Packaging data4 differ
Package widthDiffers	235 mm	120 mm
Package depthDiffers	201 mm	85 mm
Package heightDiffers	62 mm	100 mm
Package weightDiffers	390 g	183 g
Certificatesidentical
Compliance certificatesKnown for one	RoHS	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
