Product comparison · 2 network extenders

LevelOne PoE Repeater, 802.3at/af PoE vs LevelOne PoE Repeater, 2 PoE Outputs, 802.3at/af PoE

30specifications compared
5differ
25identical
2known for one product only

Key differences

Ethernet LAN (RJ-45) ports
- PoE Repeater, 802.3at/af PoE:2
- PoE Repeater, 2 PoE Outputs, 802.3at/af PoE:3
Power over Ethernet (PoE) ports quantity
- PoE Repeater, 802.3at/af PoE:2
- PoE Repeater, 2 PoE Outputs, 802.3at/af PoE:3
Width
- PoE Repeater, 802.3at/af PoE:80 mm
- PoE Repeater, 2 PoE Outputs, 802.3at/af PoE:57 mm
Depth
- PoE Repeater, 802.3at/af PoE:70 mm
- PoE Repeater, 2 PoE Outputs, 802.3at/af PoE:21 mm
Height
- PoE Repeater, 802.3at/af PoE:23 mm
- PoE Repeater, 2 PoE Outputs, 802.3at/af PoE:91 mm

Side by side

Differences highlightedShow differences only

Comparison of POR-0101, POR-0103
32 specifications	A LevelOne PoE Repeater, 802.3at/af PoE Model POR-0101 View product	B LevelOne PoE Repeater, 2 PoE Outputs, 802.3at/af PoE Model POR-0103 View product
Performanceidentical
Type	Network repeater	Network repeater
Maximum transfer distance	100 m	100 m
Data transfer rateKnown for one	100 Mbit/s	Unknown — not stated by the source
Plug and PlayKnown for one	Yes	Unknown — not stated by the source
Networkidentical
Cabling technology	10/100Base-T(X)	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ports & interfaces2 differ
Ethernet LAN (RJ-45) portsDiffers	2	3
Power over Ethernet (PoE) ports quantityDiffers	2	3
Designidentical
Product colour	Black	Black
Mounting type	Wall	Wall
LED indicators	PoE, Power	PoE, Power
Country of origin	Taiwan	Taiwan
Certification	FCC Part 15, Class B, CE	FCC Part 15, Class B, CE
Poweridentical
Power consumption (max)	2.5 W	2.5 W
Power over Ethernet (PoE)	Yes	Yes
Power over Ethernet (PoE) voltage range	46 - 57 V	46 - 57 V
Operational conditionsidentical
Operating temperature (T-T)	0 - 50 °C	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C	-20 - 70 °C
Operating relative humidity (H-H)	5 - 95%	5 - 95%
Storage relative humidity (H-H)	5 - 95%	5 - 95%
Weight & dimensions3 differ
WidthDiffers	80 mm	57 mm
DepthDiffers	70 mm	21 mm
HeightDiffers	23 mm	91 mm
Weight	200 g	200 g
Packaging contentidentical
Quick start guide	Yes	Yes
Packaging dataidentical
Package type	Box	Box
Package width	93 mm	93 mm
Package depth	43 mm	43 mm
Package height	140 mm	140 mm
Package weight	100 g	100 g
Certificatesidentical
Compliance certificates	RoHS	RoHS
Logistics dataidentical
Harmonized System (HS) code	85176990	85176990

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
