Product comparison · 2 network cards

MSI ePower 200AV+ v.II vs MSI PC60G network card Internal WLAN 54 Mbit/s

8specifications compared
8differ
0identical
23known for one product only

Key differences

Connectivity technology
- ePower 200AV+ v.II:Wired
- PC60G network card Internal WLAN 54 Mbit/s:Wireless
Host interface
- ePower 200AV+ v.II:RJ-45
- PC60G network card Internal WLAN 54 Mbit/s:PCI
Interface
- ePower 200AV+ v.II:Ethernet
- PC60G network card Internal WLAN 54 Mbit/s:WLAN
Maximum data transfer rate
- ePower 200AV+ v.II:200 Mbit/s
- PC60G network card Internal WLAN 54 Mbit/s:54 Mbit/s
Internal
- ePower 200AV+ v.II:No
- PC60G network card Internal WLAN 54 Mbit/s:Yes
Compliance industry standards
- ePower 200AV+ v.II:IEEE 802.3, IEEE 802.3u
- PC60G network card Internal WLAN 54 Mbit/s:IEEE 802.11b/g

Side by side

Differences highlightedShow differences only

Comparison of ePower 200AV+ v.II, PC60G
31 specifications	A MSI ePower 200AV+ v.II View product	B MSI PC60G network card Internal WLAN 54 Mbit/s Model PC60G View product
Ports & interfaces3 differ
Connectivity technologyDiffers	Wired	Wireless
Host interfaceDiffers	RJ-45	PCI
InterfaceDiffers	Ethernet	WLAN
Network2 differ
Maximum data transfer rateDiffers	200 Mbit/s	54 Mbit/s
Wi-Fi bandKnown for one	Unknown — not stated by the source	Single-band (2.4 GHz)
Frequency rangeKnown for one	Unknown — not stated by the source	2.4 - 2.4835 GHz
Security algorithmsDiffers	128-bit WEP	128-bit WEP, 64-bit WEP, WPA-AES, WPA-TKIP, WPA2, 802.1x RADIUS
Media access protocolKnown for one	Unknown — not stated by the source	CSMA/CA ACK
Ethernet LANKnown for one	Yes	Unknown — not stated by the source
Supported network protocolsKnown for one	TCP/IP, UDP/IP	Unknown — not stated by the source
Design1 differ
InternalDiffers	No	Yes
Receiver sensitivityKnown for one	Unknown — not stated by the source	54 Mbps OFDM@ 10% PER = -65dBm, 11 Mbps CCK@ 8% PER = -80dBm
CertificationKnown for one	Unknown — not stated by the source	FCC 15, CE, DGT, C-Tick, Wi-Fi
Product colourKnown for one	White	Unknown — not stated by the source
Poweridentical
Power consumptionKnown for one	Unknown — not stated by the source	150 mA
Power consumption (typical)Known for one	5 W	Unknown — not stated by the source
System requirements1 differ
Compatible operating systemsDiffers	Apple MacOS, Microsoft Windows 98 SE, Linux, Microsoft Windows 2000, Microsoft Windows Millennium Edition, Microsoft Windows XP, Microsoft Windows Vista	Windows 98SE/2000/ME/XP/XP 64-bit
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 70 °C
Storage temperature (T-T)Known for one	Unknown — not stated by the source	-20 - 100 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	10 - 90%
Weight & dimensionsidentical
WidthKnown for one	Unknown — not stated by the source	133.5 mm
DepthKnown for one	Unknown — not stated by the source	121 mm
HeightKnown for one	Unknown — not stated by the source	21.5 mm
WeightKnown for one	Unknown — not stated by the source	82 g
Other features1 differ
Compliance industry standardsDiffers	IEEE 802.3, IEEE 802.3u	IEEE 802.11b/g
Channels quantityKnown for one	Unknown — not stated by the source	11 channels
Supported data transfer ratesKnown for one	Unknown — not stated by the source	54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5 Mbps
Outdoor rangeKnown for one	Unknown — not stated by the source	400 m
Power requirementsKnown for one	AC 120/230 V ( 50/60 Hz )	Unknown — not stated by the source
Networking featuresKnown for one	Ethernet, Fast Ethernet, HomePlug AV (HPAV)	Unknown — not stated by the source
I/O portsKnown for one	1 x RJ-45	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
