Product comparison · 2 network cards

Fujitsu 38063057 network card Internal Ethernet 1000 Mbit/s vs Fujitsu PY-LA412 network card Internal Ethernet 100000 Mbit/s

9specifications compared
3differ
6identical
16known for one product only

Key differences

PCI version
- 38063057 network card Internal Ethernet 1000 Mbit/s:2.1
- PY-LA412 network card Internal Ethernet 100000 Mbit/s:4.0
Maximum data transfer rate
- 38063057 network card Internal Ethernet 1000 Mbit/s:1000 Mbit/s
- PY-LA412 network card Internal Ethernet 100000 Mbit/s:100000 Mbit/s
Component for
- 38063057 network card Internal Ethernet 1000 Mbit/s:PC
- PY-LA412 network card Internal Ethernet 100000 Mbit/s:Server

Side by side

Differences highlightedShow differences only

Comparison of 38063057, PY-LA412
25 specifications	A Fujitsu 38063057 network card Internal Ethernet 1000 Mbit/s Model 38063057 View product	B Fujitsu PY-LA412 network card Internal Ethernet 100000 Mbit/s Model PY-LA412 View product
Ports & interfaces1 differ
Connectivity technology	Wired	Wired
Host interface	PCI Express	PCI Express
Interface	Ethernet	Ethernet
Ethernet LAN (RJ-45) portsKnown for one	2	Unknown — not stated by the source
PCI versionDiffers	2.1	4.0
PCI Card form factor	Full-height (low-profile)	Full-height (low-profile)
Fiber optic connectorKnown for one	Unknown — not stated by the source	QSFP28
Fiber ports quantityKnown for one	Unknown — not stated by the source	2
Network1 differ
Maximum data transfer rateDiffers	1000 Mbit/s	100000 Mbit/s
Networking standardsKnown for one	IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x	Unknown — not stated by the source
Ethernet LANKnown for one	Yes	Unknown — not stated by the source
Ethernet LAN data ratesKnown for one	10,100,1000 Mbit/s	Unknown — not stated by the source
Cabling technologyKnown for one	10/100/1000BaseT(X)	Unknown — not stated by the source
Wake-on-LAN readyKnown for one	Yes	Unknown — not stated by the source
Jumbo frames supportKnown for one	Yes	Unknown — not stated by the source
LAN controllerKnown for one	Intel® I350	Unknown — not stated by the source
Design1 differ
Internal	Yes	Yes
Component forDiffers	PC	Server
ChipsetKnown for one	Intel® I350-AM2	Unknown — not stated by the source
LED indicators	Yes	Yes
Packaging dataidentical
Quantity per packKnown for one	1 pc(s)	Unknown — not stated by the source
Other featuresidentical
Flow control supportKnown for one	Yes	Unknown — not stated by the source
Poweridentical
Power consumption (typical)Known for one	Unknown — not stated by the source	18.96 W
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 55 °C
Storage temperature (T-T)Known for one	Unknown — not stated by the source	-40 - 70 °C

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
