Product comparison · 2 network cards

Cudy WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s vs Cudy WU650S network card WLAN 433 Mbit/s

24specifications compared
17differ
7identical
20known for one product only

Key differences

Host interface
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:PCI Express
- WU650S network card WLAN 433 Mbit/s:USB
Interface
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:WLAN / Bluetooth
- WU650S network card WLAN 433 Mbit/s:WLAN
Maximum data transfer rate
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:2400 Mbit/s
- WU650S network card WLAN 433 Mbit/s:433 Mbit/s
Top Wi-Fi standard
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:Wi-Fi 6 (802.11ax)
- WU650S network card WLAN 433 Mbit/s:Wi-Fi 5 (802.11ac)
WLAN data transfer rates supported
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:574,2402 Mbit/s
- WU650S network card WLAN 433 Mbit/s:200,433 Mbit/s
Internal
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:Yes
- WU650S network card WLAN 433 Mbit/s:No
Component for
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:PC
- WU650S network card WLAN 433 Mbit/s:PC/Laptop
Antenna design
- WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s:External
- WU650S network card WLAN 433 Mbit/s:Internal

Side by side

Differences highlightedShow differences only

Comparison of WE4000, WU650S
44 specifications	A Cudy WE4000 network card Internal WLAN / Bluetooth 2400 Mbit/s Model WE4000 View product	B Cudy WU650S network card WLAN 433 Mbit/s Model WU650S View product
Ports & interfaces2 differ
Connectivity technology	Wireless	Wireless
Host interfaceDiffers	PCI Express	USB
InterfaceDiffers	WLAN / Bluetooth	WLAN
PCI Card form factorKnown for one	Full-height (low-profile)	Unknown — not stated by the source
USB connector form factorKnown for one	Unknown — not stated by the source	Straight
USB versionKnown for one	Unknown — not stated by the source	2.0
Network7 differ
Maximum data transfer rateDiffers	2400 Mbit/s	433 Mbit/s
Networking standardsDiffers	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi	Yes	Yes
Wi-Fi bandDiffers	Tri-band (2.4 GHz / 5 GHz / 6 GHz)	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardDiffers	Wi-Fi 6 (802.11ax)	Wi-Fi 5 (802.11ac)
Wi-Fi standardsDiffers	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)	802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rates supportedDiffers	574,2402 Mbit/s	200,433 Mbit/s
Spread spectrum methodKnown for one	OFDMA	Unknown — not stated by the source
Security algorithmsDiffers	WPA3, WEP, WPA, WPA-PSK, WPA2-PSK, WPA2	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
BluetoothKnown for one	Yes	Unknown — not stated by the source
Bluetooth versionKnown for one	5.3	Unknown — not stated by the source
LAN controllerKnown for one	Intel AX210	Unknown — not stated by the source
Frequency rangeKnown for one	Unknown — not stated by the source	2.4 - 5.8 GHz
Design3 differ
InternalDiffers	Yes	No
Component forDiffers	PC	PC/Laptop
Antenna	Yes	Yes
Antenna designDiffers	External	Internal
Antenna gain level (max)Known for one	5 dBi	Unknown — not stated by the source
Product colourKnown for one	Unknown — not stated by the source	Black
System requirements1 differ
Windows operating systems supportedDiffers	Windows 10	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
Mac operating systems supportedKnown for one	Unknown — not stated by the source	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Operational conditions2 differ
Operating temperature (T-T)Differs	-10 - 60 °C	0 - 40 °C
Storage temperature (T-T)Differs	-20 - 70 °C	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Storage relative humidity (H-H)	5 - 90%	5 - 90%
Weight & dimensions2 differ
WidthDiffers	72 mm	36.3 mm
DepthDiffers	46 mm	19.9 mm
HeightKnown for one	2 mm	Unknown — not stated by the source
WeightKnown for one	Unknown — not stated by the source	5 g
Packaging contentidentical
Cables includedKnown for one	Coaxial	Unknown — not stated by the source
Mounting brackets includedKnown for one	Yes	Unknown — not stated by the source
Bluetooth header cableKnown for one	Yes	Unknown — not stated by the source
Resource CD	Yes	Yes
Quick installation guide	Yes	Yes
Other featuresidentical
Bracket heightKnown for one	Low-Profile (LP) / Full-Height (FH)	Unknown — not stated by the source
Poweridentical
USB poweredKnown for one	Unknown — not stated by the source	Yes
Packaging dataidentical
Quantity per packKnown for one	Unknown — not stated by the source	1 pc(s)
Package typeKnown for one	Unknown — not stated by the source	Box

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
