Product comparison · 2 network cards

ASUS M.2 CNVI WIFI CARD vs ASUS PCE-C2500 Internal Ethernet 2500 Mbit/s

10specifications compared
9differ
1identical
22known for one product only

Key differences

Connectivity technology
- M.2 CNVI WIFI CARD:Wireless
- PCE-C2500 Internal Ethernet 2500 Mbit/s:Wired
Host interface
- M.2 CNVI WIFI CARD:M.2
- PCE-C2500 Internal Ethernet 2500 Mbit/s:PCI Express
Interface
- M.2 CNVI WIFI CARD:WLAN
- PCE-C2500 Internal Ethernet 2500 Mbit/s:Ethernet
Maximum data transfer rate
- M.2 CNVI WIFI CARD:2402 Mbit/s
- PCE-C2500 Internal Ethernet 2500 Mbit/s:2500 Mbit/s
Width
- M.2 CNVI WIFI CARD:22 mm
- PCE-C2500 Internal Ethernet 2500 Mbit/s:836 mm
Depth
- M.2 CNVI WIFI CARD:30 mm
- PCE-C2500 Internal Ethernet 2500 Mbit/s:1205 mm
Height
- M.2 CNVI WIFI CARD:2.4 mm
- PCE-C2500 Internal Ethernet 2500 Mbit/s:216 mm
Weight
- M.2 CNVI WIFI CARD:2.3 g
- PCE-C2500 Internal Ethernet 2500 Mbit/s:42 g

Side by side

Differences highlightedShow differences only

Comparison of M.2 CNVI WIFI CARD, PCE-C2500
32 specifications	A ASUS M.2 CNVI WIFI CARD View product	B ASUS PCE-C2500 Internal Ethernet 2500 Mbit/s Model PCE-C2500 View product
Ports & interfaces3 differ
Connectivity technologyDiffers	Wireless	Wired
Host interfaceDiffers	M.2	PCI Express
InterfaceDiffers	WLAN	Ethernet
Ethernet LAN (RJ-45) portsKnown for one	Unknown — not stated by the source	1
Network2 differ
Maximum data transfer rateDiffers	2402 Mbit/s	2500 Mbit/s
Networking standardsDiffers	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u
Ethernet LANKnown for one	Unknown — not stated by the source	Yes
Copper ethernet cabling technologyKnown for one	Unknown — not stated by the source	100BASE-T, 1000BASE-T
Wi-FiKnown for one	Yes	Unknown — not stated by the source
Wi-Fi bandKnown for one	Dual-band (2.4 GHz / 5 GHz)	Unknown — not stated by the source
Frequency rangeKnown for one	2.4 - 5 GHz	Unknown — not stated by the source
Top Wi-Fi standardKnown for one	Wi-Fi 6 (802.11ax)	Unknown — not stated by the source
Wi-Fi standardsKnown for one	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)	Unknown — not stated by the source
WLAN data transfer rates supportedKnown for one	574,2402 Mbit/s	Unknown — not stated by the source
BluetoothKnown for one	Yes	Unknown — not stated by the source
Bluetooth versionKnown for one	5.2	Unknown — not stated by the source
Designidentical
Internal	Yes	Yes
Component forKnown for one	Unknown — not stated by the source	PC
Product colourKnown for one	Unknown — not stated by the source	Red
LED indicatorsKnown for one	Unknown — not stated by the source	Activity, Speed
ChipsetKnown for one	Intel Wi-Fi 6	Unknown — not stated by the source
System requirementsidentical
Windows operating systems supportedKnown for one	Unknown — not stated by the source	Windows 10, Windows 7, Windows 8, Windows 8.1
Linux operating systems supportedKnown for one	Unknown — not stated by the source	Yes
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 40 °C
Storage temperature (T-T)Known for one	Unknown — not stated by the source	-40 - 85 °C
Weight & dimensions4 differ
WidthDiffers	22 mm	836 mm
DepthDiffers	30 mm	1205 mm
HeightDiffers	2.4 mm	216 mm
WeightDiffers	2.3 g	42 g
Packaging dataidentical
Quantity per packKnown for one	Unknown — not stated by the source	1 pc(s)
Logistics dataidentical
Harmonized System (HS) codeKnown for one	Unknown — not stated by the source	85176990
Packaging contentidentical
Quick installation guideKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
