Product comparison · 2 network antennas

Zyxel ANT3320 network antenna Directional antenna N-type 20 dBi vs Zyxel EXT-104 network antenna Omni-directional antenna SMA 4 dBi

7specifications compared
7differ
0identical
16known for one product only

Key differences

Antenna gain level (max)
- ANT3320 network antenna Directional antenna N-type 20 dBi:20 dBi
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:4 dBi
Frequency band
- ANT3320 network antenna Directional antenna N-type 20 dBi:5.15 - 5.875 GHz
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:1.7 - 2.7 GHz
Antenna type
- ANT3320 network antenna Directional antenna N-type 20 dBi:Directional antenna
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:Omni-directional antenna
Antenna connector type
- ANT3320 network antenna Directional antenna N-type 20 dBi:N-type
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:SMA
Voltage Standing Wave Ratio (VSWR)
- ANT3320 network antenna Directional antenna N-type 20 dBi:2.0:1
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:2.0
Height
- ANT3320 network antenna Directional antenna N-type 20 dBi:165 mm
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:42 mm
Weight
- ANT3320 network antenna Directional antenna N-type 20 dBi:2.7 kg
- EXT-104 network antenna Omni-directional antenna SMA 4 dBi:100 g

Side by side

Differences highlightedShow differences only

Comparison of ANT3320, EXT-104
23 specifications	A Zyxel ANT3320 network antenna Directional antenna N-type 20 dBi Model ANT3320 View product	B Zyxel EXT-104 network antenna Omni-directional antenna SMA 4 dBi Model EXT-104 View product
Performance2 differ
Antenna gain level (max)Differs	20 dBi	4 dBi
Frequency bandDiffers	5.15 - 5.875 GHz	1.7 - 2.7 GHz
ImpedanceKnown for one	50 Ω	Unknown — not stated by the source
Networking standardsKnown for one	Unknown — not stated by the source	IEEE 802.11b
Horizontal beam widthKnown for one	Unknown — not stated by the source	360°
Features3 differ
Antenna typeDiffers	Directional antenna	Omni-directional antenna
Antenna connector typeDiffers	N-type	SMA
Voltage Standing Wave Ratio (VSWR)Differs	2.0:1	2.0
Product colourKnown for one	Grey, White	Unknown — not stated by the source
Ultraviolet (UV) resistantKnown for one	Yes	Unknown — not stated by the source
Survival wind speedKnown for one	216 km/h	Unknown — not stated by the source
Front to back ratioKnown for one	-30 dB	Unknown — not stated by the source
Sidelobes levelKnown for one	-10 dB	Unknown — not stated by the source
Maximum operating distanceKnown for one	Unknown — not stated by the source	50 m
Operational conditionsidentical
Operating temperature (T-T)Known for one	-40 - 80 °C	Unknown — not stated by the source
Weight & dimensions2 differ
WidthKnown for one	371 mm	Unknown — not stated by the source
DepthKnown for one	371 mm	Unknown — not stated by the source
HeightDiffers	165 mm	42 mm
WeightDiffers	2.7 kg	100 g
DiameterKnown for one	Unknown — not stated by the source	13.2 cm
Packaging contentidentical
Mounting kitKnown for one	Yes	Unknown — not stated by the source
Quick installation guideKnown for one	Yes	Unknown — not stated by the source
Quantity per packKnown for one	Unknown — not stated by the source	1 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
