Product comparison · 2 monitors crt

Samsung 1100P+ monitor CRT vs Samsung 17IN 20MM 1280X1024RES

13specifications compared
10differ
3identical
4known for one product only

Key differences

Display diagonal
- 1100P+ monitor CRT:53.3 cm (21")
- 17IN 20MM 1280X1024RES:43.2 cm (17")
Display resolution
- 1100P+ monitor CRT:1800 x 1440 pixels
- 17IN 20MM 1280X1024RES:1280 x 1024 pixels
Viewable size diagonal
- 1100P+ monitor CRT:50.8 cm
- 17IN 20MM 1280X1024RES:40.6 cm
Horizontal scan range
- 1100P+ monitor CRT:30 - 110 kHz
- 17IN 20MM 1280X1024RES:30 - 70 kHz
Display
- 1100P+ monitor CRT:CRT
- 17IN 20MM 1280X1024RES:Samsung DynaFlat X TM tube
Dimensions (WxDxH)
- 1100P+ monitor CRT:504 x 493 x 510 mm
- 17IN 20MM 1280X1024RES:412 x 420 x 415.5 mm
Weight
- 1100P+ monitor CRT:26.1 kg
- 17IN 20MM 1280X1024RES:16.4 kg

Side by side

Differences highlightedShow differences only

Comparison of 1100P+, 17IN 20MM 1280X1024RES
17 specifications	A Samsung 1100P+ monitor CRT Model 1100P+ View product	B Samsung 17IN 20MM 1280X1024RES View product
Display6 differ
Display diagonalDiffers	53.3 cm (21")	43.2 cm (17")
TypeDiffers	Display / CRT conventional - desktop	CRT
Display resolutionDiffers	1800 x 1440 pixels	1280 x 1024 pixels
Viewable size diagonalDiffers	50.8 cm	40.6 cm
Vertical scan range	50 - 160 Hz	50 - 160 Hz
Horizontal scan rangeDiffers	30 - 110 kHz	30 - 70 kHz
DisplayDiffers	CRT	Samsung DynaFlat X TM tube
Surface treatmentKnown for one	Unknown — not stated by the source	Multi-layer coating
Pixel pitchKnown for one	0.21	Unknown — not stated by the source
Features1 differ
Audio system	No	No
Plug and Play	Yes	Yes
CertificationDiffers	UL, CSA, NOM, TUV GS, NEMKO, EPA PSB, FCC-B, DOC-B, CE, CISPR22-B, VCCI, MPR-II, TCO'99	U L, CSA, TUV, CB, NEMKO, Korea EK, CCIB, PSB, NOM, GOST, CDRH, IRAM, FCC, CE, VCCI, C-tick, BSMI, Mic, ICES, TUV GS, MPR II, TCO95
Ports & interfacesidentical
I/O portsKnown for one	Unknown — not stated by the source	1 x 15-pin mini D-Sub
Management features1 differ
User controlsDiffers	Position, Size, Pincushion, Linearity, Pin Balance, Trapezoid, Parallel, Tilt (Rotation), Moire, Color Temperature, Color Control, Zoom In/Out, Focus, Recall, Manual Degauss, BNC/D-sub, Convergence, CG	Brightness, contrast, position, size, zoom, pincushion, trapezoid, rotation, parallelogram, pin balance, V- linearity, H/V- moiré, color temperature, degauss, video input level, halftone, recall, display timing, languages, OSD, ock/unlock
Weight & dimensions2 differ
Dimensions (WxDxH)Differs	504 x 493 x 510 mm	412 x 420 x 415.5 mm
WeightDiffers	26.1 kg	16.4 kg
Technical detailsidentical
Monitor max. video input bandwidthKnown for one	Unknown — not stated by the source	110 MHz

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
