Product comparison · 2 laptops

Lenovo ThinkPad T400s + Port Replicator vs Lenovo ThinkPad W500 + Port Replicator

99specifications compared
24differ
75identical
13known for one product only

Key differences

Display diagonal
- ThinkPad T400s + Port Replicator:35.8 cm (14.1")
- ThinkPad W500 + Port Replicator:39.1 cm (15.4")
Processor model
- ThinkPad T400s + Port Replicator:SP9600
- ThinkPad W500 + Port Replicator:T9800
Processor frequency
- ThinkPad T400s + Port Replicator:2.53 GHz
- ThinkPad W500 + Port Replicator:2.93 GHz
Processor socket
- ThinkPad T400s + Port Replicator:BGA 956
- ThinkPad W500 + Port Replicator:Socket 479
Thermal Design Power (TDP)
- ThinkPad T400s + Port Replicator:25 W
- ThinkPad W500 + Port Replicator:35 W
CPU multiplier (bus/core ratio)
- ThinkPad T400s + Port Replicator:8.5
- ThinkPad W500 + Port Replicator:11
Total storage capacity
- ThinkPad T400s + Port Replicator:128 GB
- ThinkPad W500 + Port Replicator:320 GB
Discrete graphics card model
- ThinkPad T400s + Port Replicator:Intel® GMA 4500MHD
- ThinkPad W500 + Port Replicator:AMD Mobility FireGL V5700

Side by side

Differences highlightedShow differences only

Comparison of ThinkPad T400s + Port Replicator, ThinkPad W500 + Port Replicator
112 specifications	A Lenovo ThinkPad T400s + Port Replicator View product	B Lenovo ThinkPad W500 + Port Replicator View product
Display1 differ
Display diagonalDiffers	35.8 cm (14.1")	39.1 cm (15.4")
Display resolutionKnown for one	Unknown — not stated by the source	1920 x 1200 pixels
Native aspect ratioKnown for one	Unknown — not stated by the source	16:10
Processor6 differ
Processor manufacturer	Intel	Intel
Processor family	Intel® Core™2 Duo	Intel® Core™2 Duo
Processor modelDiffers	SP9600	T9800
Processor cores	2	2
Processor threads	2	2
Processor frequencyDiffers	2.53 GHz	2.93 GHz
Processor cache	6 MB	6 MB
Processor cache type	L2	L2
Processor front side bus	1066 MHz	1066 MHz
Processor socketDiffers	BGA 956	Socket 479
Processor lithography	45 nm	45 nm
Processor operating modes	64-bit	64-bit
Processor seriesDiffers	Intel Core 2 Duo P9000 Series	Intel Core 2 Duo T9000 Series
Processor codename	Penryn	Penryn
Bus type	FSB	FSB
FSB Parity	No	No
SteppingKnown for one	Unknown — not stated by the source	E0
Thermal Design Power (TDP)Differs	25 W	35 W
Tjunction	105 °C	105 °C
Number of Processing Die Transistors	410 M	410 M
Processing Die size	107 mm²	107 mm²
CPU multiplier (bus/core ratio)Differs	8.5	11
ECC supported by processor	No	No
Memoryidentical
Internal memory	4 GB	4 GB
Memory clock speed	1066 MHz	1066 MHz
Memory layout (slots x size)Known for one	Unknown — not stated by the source	2 x 2 GB
Maximum internal memoryKnown for one	Unknown — not stated by the source	8 GB
Internal memory typeKnown for one	DDR3-SDRAM	Unknown — not stated by the source
Storage1 differ
Total storage capacityDiffers	128 GB	320 GB
HDD speedKnown for one	Unknown — not stated by the source	7200 RPM
Card reader integrated	Yes	Yes
Graphics1 differ
Discrete graphics card	Yes	Yes
Discrete graphics card modelDiffers	Intel® GMA 4500MHD	AMD Mobility FireGL V5700
Maximum graphics card memoryKnown for one	Unknown — not stated by the source	0.5 GB
Graphics card familyKnown for one	Intel	Unknown — not stated by the source
Network2 differ
Networking typeKnown for one	Unknown — not stated by the source	Vodafone WWAN
Wireless technologyDiffers	Intel 5300 AGN (3x3)	Intel Wireless WiFi Link 5300 3x3 AGN
Bluetooth	Yes	Yes
Bluetooth versionDiffers	2.1+EDR	2.0+EDR
Mobile network connectionKnown for one	Yes	Unknown — not stated by the source
Mobile network generationKnown for one	3G	Unknown — not stated by the source
Ports & interfaces2 differ
USB 2.0 ports quantity	3	3
Ethernet LAN (RJ-45) ports	0	0
HDMI ports quantity	0	0
DVI portDiffers	No	Yes
VGA (D-Sub) ports quantity	1	1
Firewire (IEEE 1394) ports	1	1
Headphone outputs	1	1
S/PDIF out port	No	No
Microphone in	Yes	Yes
Docking connector	Yes	Yes
ExpressCard slot	Yes	Yes
CardBus PCMCIA slots quantityDiffers	0	1
CardBus PCMCIA slot type	No	No
SmartCard slot	No	No
Modem (RJ-11) ports	0	0
TV-in port	No	No
TV-out	No	No
PS/2 ports quantity	0	0
Parallel ports quantity	0	0
Serial ports quantity	0	0
Softwareidentical
Operating system installed	Windows Vista Business	Windows Vista Business
Pre-installed softwareKnown for one	Unknown — not stated by the source	Windows Professional recovery media
Bundled software	vPro	vPro
Processor special features3 differ
Intel® Wireless Display (Intel® WiDi)	No	No
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	No	No
Intel 64	Yes	Yes
Intel Clear Video Technology	No	No
Intel Demand Based Switching	No	No
Intel Dual Display Capable Technology	No	No
Intel Enhanced Halt State	No	No
Intel FDI Technology	No	No
Intel Fast Memory Access	No	No
Intel Flex Memory Access	No	No
Intel Rapid Storage Technology	No	No
Intel Trusted Execution Technology	Yes	Yes
Intel VT-x with Extended Page Tables (EPT)	No	No
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No	No
Intel® AES New Instructions (Intel® AES-NI)	No	No
Intel® Anti-Theft Technology (Intel® AT)	No	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® InTru™ 3D Technology	No	No
Intel® Insider™	No	No
Intel® My WiFi Technology (Intel® MWT)	No	No
Intel® Quick Sync Video Technology	No	No
Intel® Turbo Boost Technology	No	No
Processor ARK IDDiffers	37260	37005
Processor codeDiffers	SLGER	SLGES
Processor package sizeDiffers	22 x 22 mm	35 x 35 mm
Thermal Monitoring Technologies	No	No
Conflict-Free processor	No	No
Battery2 differ
Number of battery cellsDiffers	6	9
Battery life (max)Differs	6.5 h	8.3 h
Securityidentical
Fingerprint reader	Yes	Yes
Weight & dimensions5 differ
WeightDiffers	2.13 kg	2.63 kg
WidthDiffers	335.3 mm	357.5 mm
DepthDiffers	238 mm	255 mm
HeightDiffers	27.6 mm	29.5 mm
Dimensions (WxDxH)Differs	335.3 x 238 x 27.6 mm	357.5 x 255 x 29.5 mm
Other features1 differ
Infrared data port	No	No
Internal modem	Yes	Yes
Intel segment taggingDiffers	Home office, Small Business	Professional
Supplied AC adapter type	AC	AC

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
