ASUS VX7-SZ117V laptop Intel® Core™ i7 i7-2630QM vs ASUS VX7-SZ118V laptop Intel® Core™ i7 i7-2630QM

Comparison of VX7-SZ117V, VX7-SZ118V

145 specifications	A ASUS VX7-SZ117V laptop Intel® Core™ i7 i7-2630QM Model VX7-SZ117V View product	B ASUS VX7-SZ118V laptop Intel® Core™ i7 i7-2630QM Model VX7-SZ118V View product
Design1 differ
Product colourDiffers	Black	Yellow
Displayidentical
Display diagonal	39.6 cm (15.6")	39.6 cm (15.6")
Display resolution	1920 x 1080 pixels	1920 x 1080 pixels
HD type	Full HD	Full HD
LED backlight	Yes	Yes
Native aspect ratio	16:9	16:9
Processoridentical
Processor manufacturer	Intel	Intel
Processor family	Intel® Core™ i7	Intel® Core™ i7
Processor generation	2nd gen Intel® Core™ i7	2nd gen Intel® Core™ i7
Processor model	i7-2630QM	i7-2630QM
Processor cores	4	4
Processor threads	8	8
Processor boost frequency	2.9 GHz	2.9 GHz
Processor frequency	2 GHz	2 GHz
System bus rate	5 GT/s	5 GT/s
Processor cache	6 MB	6 MB
Processor cache type	Smart Cache	Smart Cache
Processor socket	Socket 988	Socket 988
Processor lithography	32 nm	32 nm
Processor operating modes	64-bit	64-bit
Processor series	Intel Core i7-2600 Mobile Series	Intel Core i7-2600 Mobile Series
Processor codename	Sandy Bridge	Sandy Bridge
Bus type	DMI	DMI
FSB Parity	No	No
Stepping	D2	D2
Thermal Design Power (TDP)	45 W	45 W
Tjunction	100 °C	100 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurations	1x16, 2x8, 1x8+2x4	1x16, 2x8, 1x8+2x4
PCI Express slots version	2.0	2.0
CPU multiplier (bus/core ratio)	20	20
ECC supported by processor	No	No
Memoryidentical
Internal memory	8 GB	8 GB
Internal memory type	DDR3-SDRAM	DDR3-SDRAM
Memory clock speed	1333 MHz	1333 MHz
Memory slots	4x SO-DIMM	4x SO-DIMM
Maximum internal memory	16 GB	16 GB
Storageidentical
Total storage capacity	1 TB	1 TB
Number of HDDs installed	2	2
HDD capacity	500 GB	500 GB
HDD interface	SATA	SATA
HDD speed	7200 RPM	7200 RPM
Card reader integrated	Yes	Yes
Compatible memory cards	Memory Stick (MS), MiniSD, MMC, MS Duo, MS PRO, MS PRO Duo, SD, xD	Memory Stick (MS), MiniSD, MMC, MS Duo, MS PRO, MS PRO Duo, SD, xD
Graphicsidentical
On-board graphics card	Yes	Yes
Discrete graphics card	Yes	Yes
Discrete graphics card model	NVIDIA® GeForce® GTX 460M	NVIDIA® GeForce® GTX 460M
Graphics card family	NVIDIA	NVIDIA
On-board graphics card family	Intel® HD Graphics	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 3000	Intel® HD Graphics 3000
On-board graphics card base frequency	650 MHz	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz	1100 MHz
On-board graphics card ID	0x116	0x116
Audioidentical
Audio system	Azalia	Azalia
Number of built-in speakers	2	2
Audio system direct 3D sound	Yes	Yes
Networkidentical
Wi-Fi	Yes	Yes
Networking features	Gigabit Ethernet	Gigabit Ethernet
Wireless technology	Wi-Fi	Wi-Fi
Ethernet LAN	Yes	Yes
Bluetooth	No	No
Cabling technology	10/100/1000Base-T(X)	10/100/1000Base-T(X)
Integrated 4G WiMAX	Yes	Yes
Ports & interfacesidentical
USB 2.0 ports quantity	3	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1	1
eSATA/USB 2.0 ports quantity	0	0
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0	0
eSATA ports quantity	0	0
Ethernet LAN (RJ-45) ports	1	1
HDMI ports quantity	1	1
DisplayPorts quantity	0	0
DVI port	No	No
VGA (D-Sub) ports quantity	1	1
Firewire (IEEE 1394) ports	0	0
Thunderbolt ports quantity	0	0
Headphone outputs	1	1
S/PDIF out port	No	No
Microphone in	Yes	Yes
Docking connector	No	No
ExpressCard slot	No	No
CardBus PCMCIA slots quantity	0	0
CardBus PCMCIA slot type	No	No
SmartCard slot	No	No
TV-out	No	No
Performanceidentical
Motherboard chipset	Intel® HM65 Express	Intel® HM65 Express
Keyboardidentical
Pointing device	Touchpad	Touchpad
Full-size keyboard	Yes	Yes
Softwareidentical
Operating system installed	Windows 7 Home Premium	Windows 7 Home Premium
Operating system architecture	64-bit	64-bit
Processor special featuresidentical
Intel® Wireless Display (Intel® WiDi)	Yes	Yes
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Graphics & IMC lithography	32 nm	32 nm
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	No	No
Intel Demand Based Switching	No	No
Intel Dual Display Capable Technology	Yes	Yes
Intel Enhanced Halt State	Yes	Yes
Intel FDI Technology	Yes	Yes
Intel Fast Memory Access	Yes	Yes
Intel Flex Memory Access	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Rapid Storage Technology	No	No
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No	No
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® Insider™	Yes	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Turbo Boost Technology	2.0	2.0
Processor ARK ID	52219	52219
Processor code	SR02Y	SR02Y
Processor package size	37.5 x 37.5 (rPGA998)	37.5 x 37.5 (rPGA998)
Supported instruction sets	AVX	AVX
Thermal Monitoring Technologies	Yes	Yes
Conflict-Free processor	No	No
Batteryidentical
Number of battery cells	8	8
Battery capacity	5200 mAh	5200 mAh
Poweridentical
AC adapter power	150 W	150 W
AC adapter input voltage	100 - 240 V	100 - 240 V
AC adapter output current	7.7 A	7.7 A
AC adapter output voltage	19.5 V	19.5 V
DC-in jack	Yes	Yes
Securityidentical
Cable lock slot	Yes	Yes
Cable lock slot type	Kensington	Kensington
Weight & dimensionsidentical
Weight	3.82 kg	3.82 kg
Width	402 mm	402 mm
Depth	309 mm	309 mm
Height (front)	5 cm	5 cm
Height (rear)	5.79 cm	5.79 cm
Packaging contentidentical
AC adapter included	Yes	Yes
Other featuresidentical
Infrared data port	No	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Power supply type	AC/DC	AC/DC
Supplied AC adapter type	AC	AC

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
