Product comparison · 2 internal solid state drives

Goodram BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC vs Goodram DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC

Key differences

SSD capacity
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:480 GB
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:3.84 TB
M.2 SSD size
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:2280 (22 x 80 mm)
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:22110 (22 x 110 mm)
Random read (4KB)
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:250000 IOPS
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:400000 IOPS
Random write (4KB)
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:15000 IOPS
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:40000 IOPS
Read latency
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:75 µs
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:80 µs
Write latency
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:40 µs
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:25 µs
Depth
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:80 mm
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:110 mm
Weight
- BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC:11 g
- DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC:15 g

Differences highlightedShow differences only

Comparison of BS10, DC10
22 specifications	A Goodram BS10 480 GB M.2 PCI Express 4.0 NVMe 3D TLC Model BS10 View product	B Goodram DC10 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC Model DC10 View product
Features6 differ
SSD capacityDiffers	480 GB	3.84 TB
SSD form factor	M.2	M.2
Interface	PCI Express 4.0	PCI Express 4.0
NVMe	Yes	Yes
NVMe version	1.4	1.4
Memory type	3D TLC	3D TLC
Component for	Server	Server
Security algorithmsKnown for one	Unknown — not stated by the source	256-bit AES-XTS
M.2 SSD sizeDiffers	2280 (22 x 80 mm)	22110 (22 x 110 mm)
Random read (4KB)Differs	250000 IOPS	400000 IOPS
Random write (4KB)Differs	15000 IOPS	40000 IOPS
Read latencyDiffers	75 µs	80 µs
Write latencyDiffers	40 µs	25 µs
Drive writes per day (DWPD)	1	1
Mean time between failures (MTBF)	2000000 h	2000000 h
Poweridentical
Power consumption (idle)	3.5 W	3.5 W
Weight & dimensions2 differ
Width	22 mm	22 mm
DepthDiffers	80 mm	110 mm
Height	4.08 mm	4.08 mm
WeightDiffers	11 g	15 g
Operational conditionsidentical
Operating temperature (T-T)	0 - 70 °C	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
