Product comparison · 2 internal solid state drives

Goodram BS05M 480 GB 2.5" Serial ATA III 3D TLC vs Goodram PX600 LITE SSDPB-PX600L-256-80

13specifications compared
11differ
2identical
16known for one product only

Key differences

SSD capacity
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:480 GB
- PX600 LITE SSDPB-PX600L-256-80:256 GB
SSD form factor
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:2.5"
- PX600 LITE SSDPB-PX600L-256-80:M.2
Interface
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:Serial ATA III
- PX600 LITE SSDPB-PX600L-256-80:PCI Express 4.0
Memory type
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:3D TLC
- PX600 LITE SSDPB-PX600L-256-80:3D NAND
Component for
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:Server
- PX600 LITE SSDPB-PX600L-256-80:PC/Laptop
Random read (4KB)
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:90000 IOPS
- PX600 LITE SSDPB-PX600L-256-80:440000 IOPS
Random write (4KB)
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:15000 IOPS
- PX600 LITE SSDPB-PX600L-256-80:550000 IOPS
Mean time between failures (MTBF)
- BS05M 480 GB 2.5" Serial ATA III 3D TLC:2000000 h
- PX600 LITE SSDPB-PX600L-256-80:1500000 h

Side by side

Differences highlightedShow differences only

Comparison of BS05M, PX600 LITE SSDPB-PX600L-256-80
29 specifications	A Goodram BS05M 480 GB 2.5" Serial ATA III 3D TLC Model BS05M View product	B Goodram PX600 LITE SSDPB-PX600L-256-80 View product
Features8 differ
SSD capacityDiffers	480 GB	256 GB
SSD form factorDiffers	2.5"	M.2
InterfaceDiffers	Serial ATA III	PCI Express 4.0
NVMeKnown for one	Unknown — not stated by the source	Yes
Memory typeDiffers	3D TLC	3D NAND
Component forDiffers	Server	PC/Laptop
M.2 SSD sizeKnown for one	Unknown — not stated by the source	2280 (22 x 80 mm)
Read speedKnown for one	Unknown — not stated by the source	3400 MB/s
Write speedKnown for one	Unknown — not stated by the source	2000 MB/s
Random read (4KB)Differs	90000 IOPS	440000 IOPS
Random write (4KB)Differs	15000 IOPS	550000 IOPS
S.M.A.R.T. supportKnown for one	Unknown — not stated by the source	Yes
ECCKnown for one	Unknown — not stated by the source	Yes
Mean time between failures (MTBF)Differs	2000000 h	1500000 h
TBW ratingKnown for one	Unknown — not stated by the source	90
Security algorithmsKnown for one	256-bit AES	Unknown — not stated by the source
Read latencyKnown for one	120 µs	Unknown — not stated by the source
Write latencyKnown for one	50 µs	Unknown — not stated by the source
Drive writes per day (DWPD)Known for one	1	Unknown — not stated by the source
Weight & dimensions3 differ
WidthDiffers	69.8 mm	80 mm
DepthDiffers	100 mm	22 mm
HeightDiffers	7 mm	3.8 mm
WeightKnown for one	24 g	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)	0 - 70 °C	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Maximum operating temperatureKnown for one	Unknown — not stated by the source	70 °C
Minimum operating temperatureKnown for one	Unknown — not stated by the source	0 °C
Other featuresidentical
Warranty periodKnown for one	Unknown — not stated by the source	3 year(s)
Poweridentical
Power consumption (idle)Known for one	1.1 W	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
