Product comparison · 2 interface cards/adapters

Brainboxes PX-368 interface cards/adapter Internal Serial vs Brainboxes PX-823 interface cards/adapter Internal Serial

13specifications compared
2differ
11identical
11known for one product only

Key differences

Serial ports quantity
- PX-368 interface cards/adapter Internal Serial:4
- PX-823 interface cards/adapter Internal Serial:1
Serial interface type
- PX-368 interface cards/adapter Internal Serial:RS-422/485
- PX-823 interface cards/adapter Internal Serial:RS-232

Side by side

Differences highlightedShow differences only

Comparison of PX-368, PX-823
24 specifications	A Brainboxes PX-368 interface cards/adapter Internal Serial Model PX-368 View product	B Brainboxes PX-823 interface cards/adapter Internal Serial Model PX-823 View product
Ports & interfaces2 differ
Host interface	PCIe	PCIe
Output interface	Serial	Serial
Expansion card form factor	Full-height	Full-height
Serial ports quantityDiffers	4	1
Serial interface typeDiffers	RS-422/485	RS-232
Connector(s)	DB9	DB9
Designidentical
Internal	Yes	Yes
Product colour	Green	Green
Featuresidentical
FIFO (First In, First Out)	128 B	128 B
System requirementsidentical
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Technical detailsidentical
Compliance certificates	RoHS	RoHS
Weight & dimensionsidentical
WidthKnown for one	18 mm	Unknown — not stated by the source
DepthKnown for one	153 mm	Unknown — not stated by the source
HeightKnown for one	128 mm	Unknown — not stated by the source
WeightKnown for one	109 g	Unknown — not stated by the source
Other featuresidentical
Maximum operating distanceKnown for one	1200 m	Unknown — not stated by the source
Connectivity technology	Wired	Wired
Dimensions (WxDxH)Known for one	18 x 153 x 128 mm	Unknown — not stated by the source
Package dimensions (WxDxH)Known for one	Unknown — not stated by the source	145 x 150 x 44 mm
Packaging dataidentical
Package widthKnown for one	Unknown — not stated by the source	145 mm
Package depthKnown for one	Unknown — not stated by the source	150 mm
Package heightKnown for one	Unknown — not stated by the source	44 mm
Package weightKnown for one	Unknown — not stated by the source	140 g

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
