Product comparison · 2 interface cards/adapters

Axagon PCEA-PS interface cards/adapter Internal Parallel, Serial vs Axagon PCIA-S2 interface cards/adapter Internal Serial

Key differences

Host interface
- PCEA-PS interface cards/adapter Internal Parallel, Serial:PCIe
- PCIA-S2 interface cards/adapter Internal Serial:PCI
Output interface
- PCEA-PS interface cards/adapter Internal Parallel, Serial:Parallel, Serial
- PCIA-S2 interface cards/adapter Internal Serial:Serial
Expansion card standard
- PCEA-PS interface cards/adapter Internal Parallel, Serial:PCIe 1.1
- PCIA-S2 interface cards/adapter Internal Serial:PCI 2.3
Package type
- PCEA-PS interface cards/adapter Internal Parallel, Serial:Blister
- PCIA-S2 interface cards/adapter Internal Serial:Box

Differences highlightedShow differences only

Comparison of PCEA-PS, PCIA-S2
25 specifications	A Axagon PCEA-PS interface cards/adapter Internal Parallel, Serial Model PCEA-PS View product	B Axagon PCIA-S2 interface cards/adapter Internal Serial Model PCIA-S2 View product
Ports & interfaces3 differ
Host interfaceDiffers	PCIe	PCI
Output interfaceDiffers	Parallel, Serial	Serial
Expansion card form factor	Full-height / Low-profile	Full-height / Low-profile
Expansion card standardDiffers	PCIe 1.1	PCI 2.3
Serial ports quantity	2	2
Serial interface type	RS-232	RS-232
Parallel ports quantityKnown for one	1	Unknown — not stated by the source
Designidentical
Internal	Yes	Yes
Purpose	PC	PC
Country of origin	China	China
Certification	CE	CE
Featuresidentical
FIFO (First In, First Out)	256 B	256 B
Data bits	9	9
Stop bits	1, 1.5, 2	1, 1.5, 2
Flow control support	Yes	Yes
Plug and Play	Yes	Yes
System requirements1 differ
Windows operating systems supportedDiffers	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows ME, Windows Vista, Windows XP
Linux operating systems supported	Yes	Yes
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016
Other operating systems supported	DOS	DOS
Technical detailsidentical
Compliance certificates	RoHS	RoHS
Warranty period	3 year(s)	3 year(s)
Packaging data1 differ
Drivers included	Yes	Yes
Quick installation guide	Yes	Yes
Package typeDiffers	Blister	Box

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
