Product comparison · 2 gateways/controllers

D-Link DVG-2016S gateway/controller vs D-Link DVG-4032S gateway/controller

Key differences

Weight
- DVG-2016S gateway/controller:4.1 kg
- DVG-4032S gateway/controller:4.4 kg
Storage temperature (T-T)
- DVG-2016S gateway/controller:-25 - 75 °C
- DVG-4032S gateway/controller:-10 - 55 °C
Relative humidity
- DVG-2016S gateway/controller:0 - 95%
- DVG-4032S gateway/controller:0 - 90%
Safety
- DVG-2016S gateway/controller:UL
- DVG-4032S gateway/controller:UL, CUL, EN

Differences highlightedShow differences only

Comparison of DVG-2016S, DVG-4032S
22 specifications	A D-Link DVG-2016S gateway/controller Model DVG-2016S View product	B D-Link DVG-4032S gateway/controller Model DVG-4032S View product
Designidentical
Mounting type	Rack mounting	Rack mounting
LED indicators	Power	Power
Featuresidentical
Voice codecs	G.711, G.723.1, G.726, G.729A	G.711, G.723.1, G.726, G.729A
Protocolsidentical
Supported network protocols	DHCP, PPPoE, PPTP, Telnet	DHCP, PPPoE, PPTP, Telnet
Networkidentical
Networking standards	IEEE 802.3, IEEE 802.3u	IEEE 802.3, IEEE 802.3u
Cabling technology	10/100Base-T(X)	10/100Base-T(X)
Data transfer rate	0.1 Gbit/s	0.1 Gbit/s
Supported data transfer rates	10Mbit/s	10Mbit/s
Ports & interfaces1 differ
Ethernet LAN (RJ-45) ports	2	2
I/O portsDiffers	16 x FXS(RJ-21)	16 x FXS(RJ-21) 16 x FXO(RJ-21)
Poweridentical
Power requirements	90 - 260V, 50/60Hz	90 - 260V, 50/60Hz
Input voltage	90 - 260 V	90 - 260 V
Input frequency	50/60 Hz	50/60 Hz
Weight & dimensions1 differ
Size (imperial)	48.3 cm (19")	48.3 cm (19")
WeightDiffers	4.1 kg	4.4 kg
Dimensions (WxDxH)	442 x 330 x 43 mm	442 x 330 x 43 mm
Packaging contentidentical
Manual	Yes	Yes
Operational conditions2 differ
Operating temperature (T-T)	0 - 45 °C	0 - 45 °C
Storage temperature (T-T)Differs	-25 - 75 °C	-10 - 55 °C
Relative humidityDiffers	0 - 95%	0 - 90%
Certificates1 differ
Certification	FCC, CE	FCC, CE
SafetyDiffers	UL	UL, CUL, EN

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
