Product comparison · 2 gateways/controllers

Allied Telesis AT-IMG616BD-R2-BN gateway/controller vs Allied Telesis AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s

12specifications compared
9differ
3identical
24known for one product only

Key differences

Management protocols
- AT-IMG616BD-R2-BN gateway/controller:IGMP
- AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s:SNMP v1/v2/v3, Telnet
Ethernet LAN (RJ-45) ports
- AT-IMG616BD-R2-BN gateway/controller:6
- AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s:4
Weight
- AT-IMG616BD-R2-BN gateway/controller:400 g
- AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s:440 g
Dimensions (WxDxH)
- AT-IMG616BD-R2-BN gateway/controller:240 x 150 x 45 mm
- AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s:152 x 45 x 21 mm
Operating temperature (T-T)
- AT-IMG616BD-R2-BN gateway/controller:0 - 40 °C
- AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s:0 - 45 °C
Storage temperature (T-T)
- AT-IMG616BD-R2-BN gateway/controller:-20 - 70 °C
- AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s:-25 - 70 °C

Side by side

Differences highlightedShow differences only

Comparison of AT-IMG616BD-R2-BN, AT-iMG634A-R2
36 specifications	A Allied Telesis AT-IMG616BD-R2-BN gateway/controller Model AT-IMG616BD-R2-BN View product	B Allied Telesis AT-iMG634A-R2 gateway/controller 10, 100 Mbit/s Model AT-iMG634A-R2 View product
Design1 differ
LED indicatorsDiffers	Activity, LAN, Link, Power, WLAN	Yes
Featuresidentical
Voice codecsKnown for one	Unknown — not stated by the source	G.168, G.711, G.726, G.729
Performanceidentical
Internal memoryKnown for one	Unknown — not stated by the source	32 MB
Flash memoryKnown for one	Unknown — not stated by the source	8 MB
Protocols1 differ
Management protocolsDiffers	IGMP	SNMP v1/v2/v3, Telnet
DHCP clientKnown for one	Unknown — not stated by the source	Yes
DHCP serverKnown for one	Unknown — not stated by the source	Yes
DMZ supportKnown for one	Unknown — not stated by the source	Yes
Routing protocols	RIP-1, RIP-2	RIP-1, RIP-2
VoIP protocolsKnown for one	Unknown — not stated by the source	H.323 3.0, SIP 2.0, MGCP/NCS 1.0
Supported network protocolsKnown for one	PPPoE	Unknown — not stated by the source
Network1 differ
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100 Mbit/s
Networking standardsDiffers	IEEE 802.1q, IEEE 802.3ah	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
Cabling technologyKnown for one	Unknown — not stated by the source	10/100BASE-T(X)
DSL specificationKnown for one	Unknown — not stated by the source	ADSL2+
Security featuresKnown for one	Unknown — not stated by the source	SIF, NAT
VPN supportKnown for one	Unknown — not stated by the source	IPSec
Securityidentical
Authentication methodKnown for one	Unknown — not stated by the source	PAP/CHAP
DoS attack preventionKnown for one	Unknown — not stated by the source	Yes
Firewall securityKnown for one	Unknown — not stated by the source	Yes
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	6	4
Foreign eXchange Station (FXS) ports quantityKnown for one	Unknown — not stated by the source	2
WAN connectionKnown for one	Unknown — not stated by the source	ADSL (RJ-11)
InterfaceKnown for one	2 x VoIP FXS RJ-11, 1 x console port	Unknown — not stated by the source
Management featuresidentical
Quality of Service (QoS) supportKnown for one	Unknown — not stated by the source	Yes
Web-based managementKnown for one	Unknown — not stated by the source	Yes
Poweridentical
Power consumption (typical)	13 W	13 W
Input voltage	100 - 240 V	100 - 240 V
Input frequencyKnown for one	Unknown — not stated by the source	50 / 60 Hz
Output voltageKnown for one	Unknown — not stated by the source	12 V
Output currentKnown for one	Unknown — not stated by the source	1.25 A
Weight & dimensions2 differ
WeightDiffers	400 g	440 g
Dimensions (WxDxH)Differs	240 x 150 x 45 mm	152 x 45 x 21 mm
Operational conditions2 differ
Operating temperature (T-T)Differs	0 - 40 °C	0 - 45 °C
Storage temperature (T-T)Differs	-20 - 70 °C	-25 - 70 °C
Certificates1 differ
CertificationDiffers	IEC, UL, CAN/CSA, EMC	EN 50385:2002 EN 300 386 v1.3.2 (2003-05) EN 301 489-1 v1.6.1 (2005-09) EN 301 489-17 v1.2.1 (2002-08) EN 300 328 v1.7.1 (2006-05) FCC K21 UL

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
