Product comparison · 2 gateways/controllers

Allied Telesis AT-IMG2426F gateway/controller 10, 100, 1000 Mbit/s vs Allied Telesis AT-IMG634B gateway/controller 10, 100 Mbit/s

Add a product
  • 31specifications compared
  • 14differ
  • 17identical
  • 7known for one product only

Key differences

  • Management protocols
    • SNMP v1/v2, Telnet
    • SNMP v1/v2/v3, Telnet
  • Ethernet LAN data rates
    • 10,100,1000 Mbit/s
    • 10,100 Mbit/s
  • Cabling technology
    • 10/100/1000BASE-T(X)
    • 10/100BASE-T(X)
  • Ethernet LAN (RJ-45) ports
    • 6
    • 4
  • WAN connection
    • SFP
    • ADSL (RJ-11)
  • Power consumption (typical)
    • 15 W
    • 13 W
  • Output current
    • 2 A
    • 1.25 A
  • Weight
    • 590 g
    • 440 g

Side by side

Differences highlightedShow differences only
38 specifications
A

Allied Telesis

AT-IMG2426F gateway/controller 10, 100, 1000 Mbit/s

Model AT-IMG2426F

View product
B

Allied Telesis

AT-IMG634B gateway/controller 10, 100 Mbit/s

Model AT-IMG634B

View product
Designidentical
LED indicatorsYesYes
Featuresidentical
Voice codecsG.168, G.711, G.726, G.729G.168, G.711, G.726, G.729
Performanceidentical
Internal memoryKnown for one32 MB
Flash memoryKnown for one8 MB
Protocols2 differ
Management protocolsDiffersSNMP v1/v2, TelnetSNMP v1/v2/v3, Telnet
DHCP clientYesYes
DHCP serverYesYes
DMZ supportYesYes
Routing protocolsRIP-1, RIP-2RIP-1, RIP-2
VoIP protocolsDiffersSIP 2.0, MGCP/NCS 1.0H.323 3.0, SIP 2.0, MGCP/NCS 1.0
Network3 differ
Ethernet LAN data ratesDiffers10,100,1000 Mbit/s10,100 Mbit/s
Networking standardsDiffersIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3uIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
Cabling technologyDiffers10/100/1000BASE-T(X)10/100BASE-T(X)
DSL specificationKnown for oneADSL2+
Security featuresSIF, NATSIF, NAT
VPN supportIPSecIPSec
Securityidentical
Authentication methodPAP/CHAPPAP/CHAP
DoS attack preventionKnown for oneYes
Firewall securityYesYes
VLAN supportYesYes
Ports & interfaces2 differ
Ethernet LAN (RJ-45) portsDiffers64
Foreign eXchange Station (FXS) ports quantity22
WAN connectionDiffersSFPADSL (RJ-11)
USB 2.0 ports quantityKnown for one1
Management featuresidentical
Quality of Service (QoS) supportYesYes
Web-based managementYesYes
Power2 differ
Power consumption (typical)Differs15 W13 W
Input voltage100 - 240 V100 - 240 V
Input frequency50 / 60 Hz50 / 60 Hz
Output voltage12 V12 V
Output currentDiffers2 A1.25 A
Weight & dimensions2 differ
WeightDiffers590 g440 g
Dimensions (WxDxH)Differs202 x 42 x 230 mm152 x 45 x 21 mm
Operational conditions2 differ
Operating temperature (T-T)Differs-40 - 60 °C0 - 45 °C
Storage temperature (T-T)Differs-40 - 70 °C-25 - 70 °C
Operating relative humidity (H-H)Known for one5 - 95%
Certificates1 differ
CertificationDiffersFCC EN 55022 Class B EN 300 386 EN 55024EN 50385:2002 EN 300 386 v1.3.2 (2003-05) EN 301 489-1 v1.6.1 (2005-09) EN 301 489-17 v1.2.1 (2002-08) EN 300 328 v1.7.1 (2006-05) FCC K21 UL
SafetyKnown for oneEC/EN60950-1, UL 60950-1, EN60825-1, CAN/CSA-C22.2 No 60950-1-03

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
