Product comparison · 2 gateways/controllers

Allied Telesis AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s vs Allied Telesis AT-UWC-60-APL-30 gateway/controller

14specifications compared
8differ
6identical
20known for one product only

Key differences

Management protocols
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:SNMP v1/v2, Telnet
- AT-UWC-60-APL-30 gateway/controller:SNMP v1, v2c, v3
Ethernet LAN (RJ-45) ports
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:5
- AT-UWC-60-APL-30 gateway/controller:6
Power consumption (typical)
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:12 W
- AT-UWC-60-APL-30 gateway/controller:35 W
Input frequency
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:50 / 60 Hz
- AT-UWC-60-APL-30 gateway/controller:47 - 63 Hz
Weight
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:400 g
- AT-UWC-60-APL-30 gateway/controller:1.5 kg
Dimensions (WxDxH)
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:240 x 150 x 45 mm
- AT-UWC-60-APL-30 gateway/controller:210 x 210 x 42 mm
Storage temperature (T-T)
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:-20 - 70 °C
- AT-UWC-60-APL-30 gateway/controller:-10 - 70 °C

Side by side

Differences highlightedShow differences only

Comparison of AT-iMG1525RF, AT-UWC-60-APL-30
34 specifications	A Allied Telesis AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s Model AT-iMG1525RF View product	B Allied Telesis AT-UWC-60-APL-30 gateway/controller Model AT-UWC-60-APL-30 View product
Designidentical
LED indicators	Yes	Yes
Mounting typeKnown for one	Unknown — not stated by the source	Rack mounting
Featuresidentical
Voice codecsKnown for one	G.168, G.711, G.722, G.726, G.729	Unknown — not stated by the source
Protocols1 differ
Management protocolsDiffers	SNMP v1/v2, Telnet	SNMP v1, v2c, v3
DHCP client	Yes	Yes
DHCP serverKnown for one	Yes	Unknown — not stated by the source
DMZ supportKnown for one	Yes	Unknown — not stated by the source
Routing protocolsKnown for one	RIP-1, RIP-2	Unknown — not stated by the source
VoIP protocolsKnown for one	SIP 2.0, MGCP/NCS 1.0	Unknown — not stated by the source
Network1 differ
Ethernet LAN data ratesKnown for one	10,100,1000 Mbit/s	Unknown — not stated by the source
Networking standardsDiffers	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i
Security featuresKnown for one	SIF, NAT	Unknown — not stated by the source
VPN supportKnown for one	IPSec	Unknown — not stated by the source
Securityidentical
Authentication methodKnown for one	PAP/CHAP	Unknown — not stated by the source
Firewall securityKnown for one	Yes	Unknown — not stated by the source
VLAN supportKnown for one	Yes	Unknown — not stated by the source
DoS attack preventionKnown for one	Unknown — not stated by the source	Yes
Ports & interfaces1 differ
USB 2.0 ports quantity	2	2
Ethernet LAN (RJ-45) portsDiffers	5	6
Foreign eXchange Station (FXS) ports quantityKnown for one	2	Unknown — not stated by the source
WAN connectionKnown for one	Unknown — not stated by the source	Ethernet (RJ-45)
Management featuresidentical
Quality of Service (QoS) support	Yes	Yes
Web-based managementKnown for one	Yes	Unknown — not stated by the source
Power2 differ
Power consumption (typical)Differs	12 W	35 W
Input voltage	100 - 240 V	100 - 240 V
Input frequencyDiffers	50 / 60 Hz	47 - 63 Hz
Output voltageKnown for one	12 V	Unknown — not stated by the source
Output currentKnown for one	1.5 A	Unknown — not stated by the source
Weight & dimensions2 differ
WeightDiffers	400 g	1.5 kg
Dimensions (WxDxH)Differs	240 x 150 x 45 mm	210 x 210 x 42 mm
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)Differs	-20 - 70 °C	-10 - 70 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	20 - 90%
Certificatesidentical
CertificationKnown for one	IEC/EN60950-1 UL 60950-1 EN60825-1 CAN/CSA-C22.2 No 60950-1-03 FCC EN 55022 Class B EN 300 386 EN 55024	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
