Product comparison · 2 gateways/controllers

Allied Telesis AT-iMG1405 gateway/controller 10, 100, 1000 Mbit/s vs Allied Telesis AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s

27specifications compared
5differ
22identical
7known for one product only

Key differences

Weight
- AT-iMG1405 gateway/controller 10, 100, 1000 Mbit/s:450 g
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:400 g
Dimensions (WxDxH)
- AT-iMG1405 gateway/controller 10, 100, 1000 Mbit/s:260 x 150 x 45 mm
- AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s:240 x 150 x 45 mm

Side by side

Differences highlightedShow differences only

Comparison of AT-iMG1405, AT-iMG1525RF
34 specifications	A Allied Telesis AT-iMG1405 gateway/controller 10, 100, 1000 Mbit/s Model AT-iMG1405 View product	B Allied Telesis AT-iMG1525RF gateway/controller 10, 100, 1000 Mbit/s Model AT-iMG1525RF View product
Designidentical
LED indicators	Yes	Yes
Features1 differ
Voice codecsDiffers	G.168, G.711, G.726, G.729	G.168, G.711, G.722, G.726, G.729
Protocolsidentical
Management protocols	SNMP v1/v2, Telnet	SNMP v1/v2, Telnet
DHCP client	Yes	Yes
DHCP server	Yes	Yes
DMZ support	Yes	Yes
VoIP protocols	SIP 2.0, MGCP/NCS 1.0	SIP 2.0, MGCP/NCS 1.0
Routing protocolsKnown for one	Unknown — not stated by the source	RIP-1, RIP-2
Network1 differ
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Networking standardsDiffers	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ah, IEEE 802.3u, \	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Wi-FiKnown for one	No	Unknown — not stated by the source
Cabling technologyKnown for one	10/100/1000BASE-T(X)	Unknown — not stated by the source
Security features	SIF, NAT	SIF, NAT
VPN support	IPSec	IPSec
Securityidentical
Authentication method	PAP/CHAP	PAP/CHAP
Firewall security	Yes	Yes
VLAN support	Yes	Yes
Ports & interfacesidentical
USB 2.0 ports quantity	2	2
Ethernet LAN (RJ-45) ports	5	5
WAN connectionKnown for one	SFP	Unknown — not stated by the source
Foreign eXchange Station (FXS) ports quantityKnown for one	Unknown — not stated by the source	2
Management featuresidentical
Quality of Service (QoS) support	Yes	Yes
Web-based management	Yes	Yes
Poweridentical
Input voltage	100 - 240 V	100 - 240 V
Input frequency	50 / 60 Hz	50 / 60 Hz
Output voltage	12 V	12 V
Output current	1.5 A	1.5 A
Power consumption (typical)Known for one	Unknown — not stated by the source	12 W
Weight & dimensions2 differ
WeightDiffers	450 g	400 g
Dimensions (WxDxH)Differs	260 x 150 x 45 mm	240 x 150 x 45 mm
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C	-20 - 70 °C
Operating relative humidity (H-H)Known for one	5 - 95%	Unknown — not stated by the source
Certificates1 differ
CertificationDiffers	IEC/EN60950-1 UL 60950-1 EN60825-1 CAN/CSA-C22.2 GR1089 FCC EN 55022 EN 55024	IEC/EN60950-1 UL 60950-1 EN60825-1 CAN/CSA-C22.2 No 60950-1-03 FCC EN 55022 Class B EN 300 386 EN 55024

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
