Product comparison · 2 gateways/controllers

Allied Telesis AT-iBG910 gateway/controller vs Allied Telesis AT-IMG616BD-R2-BN gateway/controller

11specifications compared
8differ
3identical
11known for one product only

Key differences

Management protocols
- AT-iBG910 gateway/controller:SNMP, IGMP
- AT-IMG616BD-R2-BN gateway/controller:IGMP
Routing protocols
- AT-iBG910 gateway/controller:IP, RIP-1, RIP-2
- AT-IMG616BD-R2-BN gateway/controller:RIP-1, RIP-2
Supported network protocols
- AT-iBG910 gateway/controller:PPPoE, PPPoA, IPoA
- AT-IMG616BD-R2-BN gateway/controller:PPPoE
Ethernet LAN (RJ-45) ports
- AT-iBG910 gateway/controller:8
- AT-IMG616BD-R2-BN gateway/controller:6
Dimensions (WxDxH)
- AT-iBG910 gateway/controller:370 x 200 x 50 mm
- AT-IMG616BD-R2-BN gateway/controller:240 x 150 x 45 mm
Certification
- AT-iBG910 gateway/controller:CE, CSA, UL, FCC, RoHS
- AT-IMG616BD-R2-BN gateway/controller:IEC, UL, CAN/CSA, EMC

Side by side

Differences highlightedShow differences only

Comparison of AT-iBG910, AT-IMG616BD-R2-BN
22 specifications	A Allied Telesis AT-iBG910 gateway/controller Model AT-iBG910 View product	B Allied Telesis AT-IMG616BD-R2-BN gateway/controller Model AT-IMG616BD-R2-BN View product
Design1 differ
Mounting typeKnown for one	Rack mounting	Unknown — not stated by the source
LED indicatorsDiffers	Activity, DSL, Link, Power	Activity, LAN, Link, Power, WLAN
Performanceidentical
Internal memoryKnown for one	32 MB	Unknown — not stated by the source
Flash memoryKnown for one	8 MB	Unknown — not stated by the source
Protocols3 differ
Management protocolsDiffers	SNMP, IGMP	IGMP
Routing protocolsDiffers	IP, RIP-1, RIP-2	RIP-1, RIP-2
Supported network protocolsDiffers	PPPoE, PPPoA, IPoA	PPPoE
Networkidentical
DSL specificationKnown for one	ADSL, ADSL2+	Unknown — not stated by the source
Networking standardsKnown for one	Unknown — not stated by the source	IEEE 802.1q, IEEE 802.3ah
Securityidentical
MAC address filteringKnown for one	Yes	Unknown — not stated by the source
Firewall securityKnown for one	Yes	Unknown — not stated by the source
Ports & interfaces2 differ
InterfaceDiffers	4 x FXS RJ-11, 2 x ISDN BRI RJ-45	2 x VoIP FXS RJ-11, 1 x console port
Ethernet LAN (RJ-45) portsDiffers	8	6
Poweridentical
Input voltage	100 - 240 V	100 - 240 V
Input frequencyKnown for one	50 - 60 Hz	Unknown — not stated by the source
Power supplyKnown for one	25 W	Unknown — not stated by the source
Power consumption (typical)Known for one	Unknown — not stated by the source	13 W
Weight & dimensions1 differ
Dimensions (WxDxH)Differs	370 x 200 x 50 mm	240 x 150 x 45 mm
WeightKnown for one	Unknown — not stated by the source	400 g
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C	-20 - 70 °C
Certificates1 differ
CertificationDiffers	CE, CSA, UL, FCC, RoHS	IEC, UL, CAN/CSA, EMC

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
