Product comparison · 2 gateways/controllers

Allied Telesis Active ethernet Multiservice Gateway vs Allied Telesis ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports

11specifications compared
9differ
2identical
13known for one product only

Key differences

Internal memory
- Active ethernet Multiservice Gateway:16 MB
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:32 MB
Management protocols
- Active ethernet Multiservice Gateway:SNMP v1, v2, v3
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:Telnet, CLI, SNMP
Power requirements
- Active ethernet Multiservice Gateway:100-240, 50/60, 12V, 1.5A
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:100-240, 50/60
Power consumption (typical)
- Active ethernet Multiservice Gateway:8.2 W
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:13 W
Weight
- Active ethernet Multiservice Gateway:400 g
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:440 g
Dimensions (WxDxH)
- Active ethernet Multiservice Gateway:240 x 150 x 45 mm
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:200 x 150 x 48 mm
Operating relative humidity (H-H)
- Active ethernet Multiservice Gateway:10 - 80%
- ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports:0 - 80%

Side by side

Differences highlightedShow differences only

Comparison of Active ethernet Multiservice Gateway, ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports
24 specifications	A Allied Telesis Active ethernet Multiservice Gateway View product	B Allied Telesis ADSL2/2+ based intelligent Multiservice Gateway w/ 802.11b/g, 2x FXS VoIP & 4x LAN ports View product
Featuresidentical
Plug and PlayKnown for one	Yes	Unknown — not stated by the source
Voice codecsKnown for one	Unknown — not stated by the source	G.711, G.726, G.729
Performance1 differ
Internal memoryDiffers	16 MB	32 MB
Data transmissionidentical
Receiver sensitivityKnown for one	Max sensitivity -32 dBm, Max input power -3 dBm, Max output power -5 dBm	Unknown — not stated by the source
Protocols1 differ
Management protocolsDiffers	SNMP v1, v2, v3	Telnet, CLI, SNMP
Routing protocolsKnown for one	IP	Unknown — not stated by the source
Supported network protocolsKnown for one	Unknown — not stated by the source	PPPoE, PPPoA, IPoA
Supported protocolsKnown for one	Unknown — not stated by the source	H.323, SIP, MGCP/NCS
Networkidentical
Networking standardsKnown for one	IEEE 802.3z, IEEE 802.3q, IEEE 802.3p	Unknown — not stated by the source
Securityidentical
MAC address filteringKnown for one	Yes	Unknown — not stated by the source
Authentication methodKnown for one	PAP/CHAP	Unknown — not stated by the source
Ports & interfaces1 differ
I/O portsDiffers	6 x RJ45, 1 x 100LX	4x 10/100TX (RJ-45) 1x Annex A ADSL2/2+ (RJ-11)
Expansion slotsKnown for one	FXS x 2	Unknown — not stated by the source
Power2 differ
Power requirementsDiffers	100-240, 50/60, 12V, 1.5A	100-240, 50/60
Power consumption (typical)Differs	8.2 W	13 W
Power over Ethernet (PoE)Known for one	No	Unknown — not stated by the source
Weight & dimensions2 differ
WeightDiffers	400 g	440 g
Dimensions (WxDxH)Differs	240 x 150 x 45 mm	200 x 150 x 48 mm
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C	-20 - 70 °C
Operating relative humidity (H-H)Differs	10 - 80%	0 - 80%
Certificates1 differ
SafetyDiffers	EN 60950	EN 60950, CSA 950/US, UL 1950, FCC Part 68
CertificationKnown for one	Unknown — not stated by the source	CE, UL FCC Part 15 Class B EN55022 Class B EN61000-3-2, EN61000-3-3, EN55024
Designidentical
LED indicatorsKnown for one	Unknown — not stated by the source	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
