Product comparison · 2 embedded computers

NEC 100014386 embedded computer vs NEC 100014725 embedded computer

97specifications compared
46differ
51identical
38known for one product only

Key differences

Processor frequency
- 100014386 embedded computer:1.6 GHz
- 100014725 embedded computer:2.8 GHz
Processor family
- 100014386 embedded computer:Intel® Celeron®
- 100014725 embedded computer:Intel® Core™ i7
Processor model
- 100014386 embedded computer:N3160
- 100014725 embedded computer:i7-6820EQ
Processor boost frequency
- 100014386 embedded computer:2.24 GHz
- 100014725 embedded computer:3.5 GHz
Processor socket
- 100014386 embedded computer:BGA 1170
- 100014725 embedded computer:BGA 1440
Processor cache
- 100014386 embedded computer:2 MB
- 100014725 embedded computer:8 MB
Processor cache type
- 100014386 embedded computer:L2
- 100014725 embedded computer:Smart Cache
Processor threads
- 100014386 embedded computer:4
- 100014725 embedded computer:8

Side by side

Differences highlightedShow differences only

Comparison of 100014386, 100014725
135 specifications	A NEC 100014386 embedded computer Model 100014386 View product	B NEC 100014725 embedded computer Model 100014725 View product
Processor19 differ
Processor frequencyDiffers	1.6 GHz	2.8 GHz
Processor familyDiffers	Intel® Celeron®	Intel® Core™ i7
Processor modelDiffers	N3160	i7-6820EQ
Processor cores	4	4
Processor boost frequencyDiffers	2.24 GHz	3.5 GHz
Processor socketDiffers	BGA 1170	BGA 1440
Processor cacheDiffers	2 MB	8 MB
Processor cache typeDiffers	L2	Smart Cache
Processor threadsDiffers	4	8
PCI Express slots versionDiffers	2.0	3.0
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
SteppingDiffers	D1	R0
Processor codenameDiffers	Braswell	Skylake
Thermal Design Power (TDP)Differs	6 W	45 W
Processor seriesDiffers	Intel Celeron N3000 series	Intel Core i7-6800 Mobile Series
Maximum number of PCI Express lanesDiffers	4	16
PCI Express configurationsDiffers	1x2+2x1, 1x4, 2x2, 4x1	1x16, 1x8+2x4, 2x8
TjunctionDiffers	90 °C	100 °C
Scenario Design Power (SDP)Known for one	4 W	Unknown — not stated by the source
Integrated 4G WiMAXKnown for one	No	Unknown — not stated by the source
Maximum internal memory supported by processorDiffers	8 GB	64 GB
Conflict-Free processor	Yes	Yes
Memory types supported by processorDiffers	DDR3L-SDRAM	DDR3L-SDRAM, DDR4-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processorDiffers	1600 MHz	1600,1866,2133 MHz
ECC supported by processor	No	No
Processor generationKnown for one	Unknown — not stated by the source	6th gen Intel® Core™ i7
System bus rateKnown for one	Unknown — not stated by the source	8 GT/s
Bus typeKnown for one	Unknown — not stated by the source	DMI3
Memory bandwidth supported by processor (max)Known for one	Unknown — not stated by the source	34.1 GB/s
Memory4 differ
Internal memory	4 GB	4 GB
Internal memory typeDiffers	DDR3L-SDRAM	DDR4-SDRAM
Maximum internal memoryDiffers	8 GB	16 GB
Memory layout (slots x size)	1 x 4 GB	1 x 4 GB
Memory slotsDiffers	1x SO-DIMM	2x SO-DIMM
Memory clock speedDiffers	1600 MHz	2133 MHz
Memory channels	Dual-channel	Dual-channel
Storage3 differ
Total storage capacityDiffers	64 GB	128 GB
Storage media	SSD	SSD
Card reader integrated	Yes	Yes
SSD interfaceDiffers	M.2	Micro Serial ATA III
SSD capacityDiffers	64 GB	128 GB
Compatible memory cardsKnown for one	Unknown — not stated by the source	SD
Graphics3 differ
On-board graphics card	Yes	Yes
On-board graphics card modelDiffers	Intel® HD Graphics 400	Intel® HD Graphics 530
Maximum on-board graphics card memoryDiffers	8 GB	64 GB
On-board graphics card base frequencyDiffers	320 MHz	350 MHz
On-board graphics card burst frequencyKnown for one	640 MHz	Unknown — not stated by the source
On-board graphics card DirectX version	12.0	12.0
Discrete graphics card	No	No
Discrete graphics card model	Not available	Not available
Number of execution unitsKnown for one	12	Unknown — not stated by the source
Number of displays supported (on-board graphics)	3	3
On-board graphics card dynamic frequency (max)Known for one	Unknown — not stated by the source	1000 MHz
On-board graphics card OpenGL versionKnown for one	Unknown — not stated by the source	4.4
On-board graphics card IDKnown for one	Unknown — not stated by the source	0x191B
Network1 differ
Wi-FiDiffers	No	Yes
Cabling technology	10/100/1000Base-T(X)	10/100/1000Base-T(X)
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Wake-on-LAN ready	Yes	Yes
Ports & interfaces3 differ
USB 2.0 ports quantityDiffers	2	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0	0
HDMI ports quantity	0	0
DVI port	No	No
VGA (D-Sub) ports quantity	0	0
Ethernet LAN (RJ-45) ports	1	1
Headphone outputsDiffers	0	1
Microphone inDiffers	No	Yes
Mini DisplayPorts quantityKnown for one	Unknown — not stated by the source	1
Performanceidentical
BIOS memory sizeKnown for one	128 Mbit	Unknown — not stated by the source
Product colour	Black	Black
BIOS typeKnown for one	AMI	Unknown — not stated by the source
Motherboard chipsetKnown for one	Unknown — not stated by the source	Intel QM170
Audio chipKnown for one	Unknown — not stated by the source	Realtek ALC887
Software1 differ
Operating system installedDiffers	No	Windows 10 IoT Enterprise
Processor special features10 differ
Processor codeDiffers	SR2KP	SR2DT
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Intel® Anti-Theft Technology (Intel® AT)Known for one	No	Unknown — not stated by the source
Intel® Smart Response TechnologyKnown for one	No	Unknown — not stated by the source
Intel Smart Connect TechnologyKnown for one	No	Unknown — not stated by the source
Intel® Hyper Threading Technology (Intel® HT Technology)Differs	No	Yes
Intel® Turbo Boost TechnologyDiffers	No	2.0
Intel® Quick Sync Video Technology	Yes	Yes
Intel® InTru™ 3D TechnologyDiffers	No	Yes
Intel® Wireless Display (Intel® WiDi)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Insider™Differs	No	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Thermal Monitoring Technologies	Yes	Yes
Intel Trusted Execution TechnologyDiffers	No	Yes
Intel Enhanced Halt State	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Embedded options available	Yes	Yes
Intel Rapid Storage TechnologyKnown for one	No	Unknown — not stated by the source
Intel® High Definition Audio (Intel® HD Audio)Known for one	Yes	Unknown — not stated by the source
Intel® Small Business Advantage (Intel® SBA)Known for one	No	Unknown — not stated by the source
Intel® Secure Key	Yes	Yes
Intel 64	Yes	Yes
Intel Stable Image Platform Program (SIPP)Known for one	No	Unknown — not stated by the source
Intel® OS GuardDiffers	No	Yes
UARTKnown for one	Yes	Unknown — not stated by the source
Intel Virtualization Technology for Directed I/O (VT-d)Differs	No	Yes
Intel Secure BootKnown for one	Yes	Unknown — not stated by the source
Intel Clear Video Technology	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Secure Key Technology version	1.00	1.00
Intel Small Business Advantage (SBA) versionKnown for one	0.00	Unknown — not stated by the source
Intel Smart Response Technology versionKnown for one	0.00	Unknown — not stated by the source
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Smart Connect Technology versionKnown for one	0.00	Unknown — not stated by the source
Processor package sizeDiffers	25 x 27 mm	42 x 28 mm
Processor ARK IDDiffers	91831	90426
Supported instruction setsKnown for one	Unknown — not stated by the source	AVX 2.0, SSE4.1, SSE4.2
Graphics & IMC lithographyKnown for one	Unknown — not stated by the source	14 nm
Intel TSX-NIKnown for one	Unknown — not stated by the source	Yes
Intel Software Guard Extensions (Intel SGX)Known for one	Unknown — not stated by the source	Yes
Intel TSX-NI versionKnown for one	Unknown — not stated by the source	1.00
Poweridentical
Power consumption (typical)Known for one	15 W	Unknown — not stated by the source
Certificatesidentical
Certification	CE/FCC	CE/FCC
Weight & dimensions2 differ
Width	120 mm	120 mm
Depth	200 mm	200 mm
Height	30 mm	30 mm
Weight	900 g	900 g
Package widthDiffers	190 mm	200 mm
Package depth	260 mm	260 mm
Package heightDiffers	70 mm	60 mm
Package weight	1 kg	1 kg
Packaging contentidentical
ManualKnown for one	Yes	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 40 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	0 - 90%

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
