Product comparison · 2 electric vehicle charging stations

Legrand 058042 electric vehicle charging station Black Steel 1 vs Legrand 058043 electric vehicle charging station Black Steel 1

Key differences

Sockets quantity
- 058042 electric vehicle charging station Black Steel 1:2
- 058043 electric vehicle charging station Black Steel 1:1
Maximum operating power (single-phase)
- 058042 electric vehicle charging station Black Steel 1:4.6 kW
- 058043 electric vehicle charging station Black Steel 1:7.4 kW

Differences highlightedShow differences only

Comparison of 058042, 058043
30 specifications	A Legrand 058042 electric vehicle charging station Black Steel 1 Model 058042 View product	B Legrand 058043 electric vehicle charging station Black Steel 1 Model 058043 View product
Designidentical
Product colour	Black	Black
Housing material	Steel	Steel
Built-in display	No	No
Integrated energy meter	No	No
Features1 differ
Open Charge Point Protocol (OCPP) version	1.6J	1.6J
Integrated miniature circuit breaker (MCB)	Yes	Yes
Bluetooth	Yes	Yes
Socket type	Type 2	Type 2
Sockets quantityDiffers	2	1
SIM card support	No	No
RFID reader	Yes	Yes
Programmable	Yes	Yes
Communication protocol	Bluetooth / OCCP 1.6J	Bluetooth / OCCP 1.6J
Mechanical impact protection code	IK10	IK10
International Protection (IP) code	IP55	IP55
Quantity per pack	1 pc(s)	1 pc(s)
Power1 differ
Number of phases	1	1
Power source type	AC	AC
Nominal voltage	220 V	220 V
Nominal frequency	50 Hz	50 Hz
Minimum operating power (single-phase)Known for one	3.7 kW	Unknown — not stated by the source
Maximum operating power (single-phase)Differs	4.6 kW	7.4 kW
Adjustable power	Yes	Yes
Maximum operating current per phaseKnown for one	Unknown — not stated by the source	32 A
Technical detailsidentical
Compliance certificates	CE	CE
Operational conditionsidentical
Operating temperature (T-T)	-25 - 50 °C	-25 - 50 °C
Storage temperature (T-T)	-25 - 70 °C	-25 - 70 °C
Weight & dimensionsidentical
Width	430 mm	430 mm
Depth	243 mm	243 mm
Height	740 mm	740 mm

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
