Product comparison · 2 data projectors

Canon LV -7500 data projector Standard throw projector 1400 ANSI lumens 3LCD XGA (1024x768) Black vs Canon LV -7510 data projector Standard throw projector 1900 ANSI lumens 3LCD XGA (1024x768) Black

54specifications compared
3differ
51identical
0known for one product only

Key differences

Projector brightness
- LV -7500 data projector Standard throw projector 1400 ANSI lumens 3LCD XGA (1024x768) Black:1400 ANSI lumens
- LV -7510 data projector Standard throw projector 1900 ANSI lumens 3LCD XGA (1024x768) Black:1900 ANSI lumens
Lamp type
- LV -7500 data projector Standard throw projector 1400 ANSI lumens 3LCD XGA (1024x768) Black:SID
- LV -7510 data projector Standard throw projector 1900 ANSI lumens 3LCD XGA (1024x768) Black:UHP
Lamp power
- LV -7500 data projector Standard throw projector 1400 ANSI lumens 3LCD XGA (1024x768) Black:160 W
- LV -7510 data projector Standard throw projector 1900 ANSI lumens 3LCD XGA (1024x768) Black:150 W

Side by side

Differences highlightedShow differences only

Comparison of LV-7500, LV-7510
54 specifications	A Canon LV -7500 data projector Standard throw projector 1400 ANSI lumens 3LCD XGA (1024x768) Black Model LV-7500 View product	B Canon LV -7510 data projector Standard throw projector 1900 ANSI lumens 3LCD XGA (1024x768) Black Model LV-7510 View product
Projector1 differ
Projector brightnessDiffers	1400 ANSI lumens	1900 ANSI lumens
Projection technology	3LCD	3LCD
Projector native resolution	XGA (1024x768)	XGA (1024x768)
Contrast ratio (typical)	350:1	350:1
Native aspect ratio	4:3	4:3
Supported aspect ratios	4:3	4:3
Screen size compatibility	457.2 - 7620 mm (18 - 300")	457.2 - 7620 mm (18 - 300")
Projection distance	1.4 - 10.8 m	1.4 - 10.8 m
Number of colours	16.78 million colours	16.78 million colours
Horizontal scan range	15 - 100 kHz	15 - 100 kHz
Vertical scan range	50 - 100 Hz	50 - 100 Hz
Matrix size	3.3 cm (1.3")	3.3 cm (1.3")
Matrix type	3-panel (p-Si TFT active)	3-panel (p-Si TFT active)
Light source2 differ
Light source type	Lamp	Lamp
Lamp typeDiffers	SID	UHP
Lamp powerDiffers	160 W	150 W
Lamps quantity	1 lamp(s)	1 lamp(s)
Lens systemidentical
Focus	Manual	Manual
Focal length range	48 - 63 mm	48 - 63 mm
Aperture range (F-F)	1.8 - 2.1	1.8 - 2.1
Zoom capability	Yes	Yes
Zoom type	Auto	Auto
Videoidentical
Analog signal format system	NTSC, PAL, SECAM	NTSC, PAL, SECAM
Full HD	No	No
3D	No	No
Supported graphics resolutions	1024 x 768 (XGA)	1024 x 768 (XGA)
Ports & interfacesidentical
VGA (D-Sub) ports quantity	2	2
DVI port	No	No
S-Video inputs quantity	1	1
Headphone outputs	1	1
PC in (D-Sub)	Yes	Yes
AC (power) in	Yes	Yes
Networkidentical
Ethernet LAN	No	No
Wi-Fi	No	No
Storageidentical
Card reader integrated	No	No
Multimediaidentical
Built-in speaker(s)	Yes	Yes
Number of built-in speakers	2	2
RMS rated power	4 W	4 W
Designidentical
Product type	Standard throw projector	Standard throw projector
Product colour	Black	Black
Placement	Desktop	Desktop
Displayidentical
Built-in display	No	No
Poweridentical
Power source	AC	AC
Power consumption (typical)	250 W	250 W
AC input voltage	100 V	100 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Operational conditionsidentical
Operating temperature (T-T)	5 - 35 °C	5 - 35 °C
Weight & dimensionsidentical
Weight	6.6 kg	6.6 kg
Width	272 mm	272 mm
Depth	413 mm	413 mm
Height	138 mm	138 mm
Packaging contentidentical
Remote control included	Yes	Yes
Manual	Yes	Yes
Other featuresidentical
Number of bulbs	1 bulb(s)	1 bulb(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
