Product comparison · 2 data projectors

Canon LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey vs Canon LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey

54specifications compared
18differ
36identical
3known for one product only

Key differences

Projector brightness
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:700 ANSI lumens
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:1100 ANSI lumens
Projector native resolution
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:SVGA (800x600)
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:XGA (1024x768)
Contrast ratio (typical)
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:250:1
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:300:1
Screen size compatibility
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:762 - 5080 mm (30 - 200")
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:863.6 - 5080 mm (34 - 200")
Projection distance
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:1.4 - 8 m
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:1.6 - 8.1 m
Lamp power
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:120 W
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:150 W
Focal length range
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:28 - 33.6 mm
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:28.7 - 34.5 mm
Aperture range (F-F)
- LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey:2 - 2.3
- LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey:1.6 - 1.78

Side by side

Differences highlightedShow differences only

Comparison of LV-5100, X1
57 specifications	A Canon LV -5100 data projector Standard throw projector 700 ANSI lumens 3LCD SVGA (800x600) Blue, Grey Model LV-5100 View product	B Canon LV X1 Standard throw projector 1100 ANSI lumens 3LCD XGA (1024x768) Grey Model X1 View product
Projector5 differ
Projector brightnessDiffers	700 ANSI lumens	1100 ANSI lumens
Projection technology	3LCD	3LCD
Projector native resolutionDiffers	SVGA (800x600)	XGA (1024x768)
Contrast ratio (typical)Differs	250:1	300:1
Native aspect ratio	4:3	4:3
Supported aspect ratios	4:3	4:3
Screen size compatibilityDiffers	762 - 5080 mm (30 - 200")	863.6 - 5080 mm (34 - 200")
Projection distanceDiffers	1.4 - 8 m	1.6 - 8.1 m
Number of colours	16.78 million colours	16.78 million colours
Horizontal scan range	15 - 100 kHz	15 - 100 kHz
Vertical scan range	50 - 100 Hz	50 - 100 Hz
Matrix size	1.78 cm (0.7")	1.78 cm (0.7")
Matrix type	3-panel (p-Si TFT active)	3-panel (p-Si TFT active)
Light source1 differ
Light source type	Lamp	Lamp
Lamp type	UHP	UHP
Lamp powerDiffers	120 W	150 W
Lamps quantity	1 lamp(s)	1 lamp(s)
Lens system3 differ
Focus	Manual	Manual
Focal length rangeDiffers	28 - 33.6 mm	28.7 - 34.5 mm
Aperture range (F-F)Differs	2 - 2.3	1.6 - 1.78
Zoom capability	Yes	Yes
Zoom typeDiffers	Auto	Manual
Video1 differ
Analog signal format system	NTSC, PAL, SECAM	NTSC, PAL, SECAM
Full HD	No	No
3D	No	No
Supported graphics resolutionsDiffers	800 x 600 (SVGA)	1024 x 768 (XGA)
Ports & interfacesidentical
VGA (D-Sub) ports quantity	1	1
Component video (YPbPr/YCbCr) in	1	1
DVI portKnown for one	Unknown — not stated by the source	No
S-Video inputs quantityKnown for one	Unknown — not stated by the source	1
Audio (L/R) in	1	1
Headphone outputs	1	1
PC in (D-Sub)	Yes	Yes
AC (power) in	Yes	Yes
Networkidentical
Ethernet LAN	No	No
Wi-Fi	No	No
Storageidentical
Card reader integrated	No	No
Features1 differ
Noise levelDiffers	39 dB	37 dB
Multimediaidentical
Built-in speaker(s)	Yes	Yes
Number of built-in speakers	1	1
RMS rated power	1 W	1 W
Design1 differ
Product type	Standard throw projector	Standard throw projector
Product colourDiffers	Blue, Grey	Grey
Placement	Desktop	Desktop
Displayidentical
Built-in display	No	No
Power1 differ
Power source	AC	AC
Power consumption (typical)Differs	200 W	250 W
AC input voltage	100 V	100 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Operational conditionsidentical
Operating temperature (T-T)	5 - 35 °C	5 - 35 °C
Weight & dimensions4 differ
WeightDiffers	2.7 kg	2.8 kg
WidthDiffers	189 mm	260 mm
DepthDiffers	310.8 mm	230 mm
HeightDiffers	75.5 mm	76 mm
Packaging content1 differ
Remote control includedDiffers	Yes	No
Manual	Yes	Yes
Other featuresidentical
Number of bulbsKnown for one	1 bulb(s)	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
