Product comparison · 2 bridges & repeaters

Zebra CB 3000 vs Zebra Motorola CB3000 54 Mbit/s

15specifications compared
10differ
5identical
14known for one product only

Key differences

Frequency band
- CB 3000:2.4 - 5.825 GHz
- Motorola CB3000 54 Mbit/s:2.4/5 GHz
Cabling technology
- CB 3000:10/100Base-T(X)
- Motorola CB3000 54 Mbit/s:10/100/1000BASE-TX
Connectivity technology
- CB 3000:Wired
- Motorola CB3000 54 Mbit/s:Wireless
Data link protocols
- CB 3000:TCP/IP, DHCP, SNMP v2
- Motorola CB3000 54 Mbit/s:TCP/IP
Operating temperature (T-T)
- CB 3000:32 - 122 °F
- Motorola CB3000 54 Mbit/s:0 - 50 °C
Dimensions (WxDxH)
- CB 3000:102 x 179 x 31 mm
- Motorola CB3000 54 Mbit/s:102 x 31 x 179 mm

Side by side

Differences highlightedShow differences only

Comparison of CB 3000, CB3000
29 specifications	A Zebra CB 3000 View product	B Zebra Motorola CB3000 54 Mbit/s Model CB3000 View product
Data transmissionidentical
Maximum data transfer rate	54 Mbit/s	54 Mbit/s
Supported data transfer ratesKnown for one	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 35, 48, 54 Mb/s	Unknown — not stated by the source
Wireless LAN features1 differ
Frequency bandDiffers	2.4 - 5.825 GHz	2.4/5 GHz
Spread spectrum method	DSSS	DSSS
Modulation	OFDM	OFDM
Outdoor rangeKnown for one	Unknown — not stated by the source	300 m
Network2 differ
Ethernet LANKnown for one	Unknown — not stated by the source	Yes
Networking standardsDiffers	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.1d, IEEE 802.11i, IEEE 802.11h	IEEE 802.3, IEEE 802.3u, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.1x, IEEE 802.1d, IEEE 802.11h
Cabling technologyDiffers	10/100Base-T(X)	10/100/1000BASE-TX
Ports & interfaces1 differ
Connectivity technologyDiffers	Wired	Wireless
Ethernet LAN (RJ-45) ports	1	1
DC-in jackKnown for one	Unknown — not stated by the source	Yes
InterfaceKnown for one	RJ-45	Unknown — not stated by the source
Security1 differ
Security algorithmsDiffers	EAP, WPA2	802.1x RADIUS, EAP-TLS, EAP-TTLS, HTTPS, PEAP, WPA2
Management features1 differ
Management protocolsKnown for one	Unknown — not stated by the source	SNMP v2
Web-based managementKnown for one	Unknown — not stated by the source	Yes
DHCP clientKnown for one	Unknown — not stated by the source	Yes
DHCP serverKnown for one	Unknown — not stated by the source	Yes
Data link protocolsDiffers	TCP/IP, DHCP, SNMP v2	TCP/IP
Featuresidentical
LED indicatorsKnown for one	Unknown — not stated by the source	Yes
Power LEDKnown for one	Unknown — not stated by the source	Yes
Connectivity LEDsKnown for one	Yes	Unknown — not stated by the source
System requirements1 differ
Compatible operating systemsDiffers	Windows 2000, Windows XP; Mac, Apple, Linux, Unix.	Windows 2000 Windows XP
Operational conditions1 differ
Operating temperature (T-T)Differs	32 - 122 °F	0 - 50 °C
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Operating altitudeKnown for one	0 - 300 m	Unknown — not stated by the source
Certificates1 differ
CertificationDiffers	cUL1950, EN60950, IEC60950, FCC, ICES-003, EU EN 301 489, EN 60601-1-2, FCC, RSS-210, EU EN 300 328, EN 301 893, ARIB STD-66, 33 & T7.	cUL, EN, IEC, FCC
Weight & dimensions1 differ
Dimensions (WxDxH)Differs	102 x 179 x 31 mm	102 x 31 x 179 mm
Antennaidentical
Antenna gain level (max)Known for one	15 dBi	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
