Product comparison · 2 bridges & repeaters

NETGEAR Space-saving Powerline Network Extender Kit vs NETGEAR Wall-Plugged Ethernet Bridge XE102

8specifications compared
6differ
2identical
12known for one product only

Key differences

Cabling technology
- Space-saving Powerline Network Extender Kit:10/100Base-T(X)
- Wall-Plugged Ethernet Bridge XE102:10Base-T(X)
Power requirements
- Space-saving Powerline Network Extender Kit:AC 100-240V
- Wall-Plugged Ethernet Bridge XE102:220V@ 50 Hz
Operating temperature (T-T)
- Space-saving Powerline Network Extender Kit:0 - 40 °C
- Wall-Plugged Ethernet Bridge XE102:0 - 45 °C
Dimensions (WxDxH)
- Space-saving Powerline Network Extender Kit:46 x 70 x 125 mm
- Wall-Plugged Ethernet Bridge XE102:99.4 x 46.6 x 73 mm

Side by side

Differences highlightedShow differences only

Comparison of Space-saving Powerline Network Extender Kit, Wall-Plugged Ethernet Bridge XE102
20 specifications	A NETGEAR Space-saving Powerline Network Extender Kit View product	B NETGEAR Wall-Plugged Ethernet Bridge XE102 View product
Wireless LAN featuresidentical
Frequency bandKnown for one	Unknown — not stated by the source	0.0043 - 0.0209 GHz
Indoor rangeKnown for one	Unknown — not stated by the source	45 m²
ModulationKnown for one	OFDM	Unknown — not stated by the source
Network2 differ
Ethernet LANKnown for one	Unknown — not stated by the source	Yes
Networking standardsDiffers	IEEE 802.3, IEEE 802.3u, IEEE 802.3x	IEEE 802.3
Cabling technologyDiffers	10/100Base-T(X)	10Base-T(X)
Ports & interfacesidentical
Connectivity technology	Wired	Wired
InterfaceKnown for one	Unknown — not stated by the source	RJ-45
I/O portsKnown for one	Unknown — not stated by the source	1x 10BASE-T Ethernet 1x 14 Mbps Powerline
Featuresidentical
LED indicatorsKnown for one	Unknown — not stated by the source	Yes
System requirements1 differ
Compatible operating systemsDiffers	Microsoft Windows Vista, XP,2000, ME / 98SE	Windows 98/ME/2000/XP
Power1 differ
Power requirementsDiffers	AC 100-240V	220V@ 50 Hz
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 40 °C	0 - 45 °C
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Storage temperature (T-T)Known for one	-25 - 70 °C	Unknown — not stated by the source
Storage relative humidity (H-H)Known for one	5 - 95%	Unknown — not stated by the source
Certificatesidentical
Electromagnetic emissionsKnown for one	Unknown — not stated by the source	FCC Part 15 Class B
Weight & dimensions1 differ
Dimensions (WxDxH)Differs	46 x 70 x 125 mm	99.4 x 46.6 x 73 mm
WeightKnown for one	Unknown — not stated by the source	224 g
Data transmissionidentical
Maximum data transfer rateKnown for one	100 Mbit/s	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
