Product comparison · 2 bridges & repeaters

Linksys Wireless-G Ethernet Bridge vs Linksys Wireless-G Ethernet Bridge with 5-port Switch

14specifications compared
8differ
6identical
6known for one product only

Key differences

Security algorithms
- Wireless-G Ethernet Bridge:WEP, WPA
- Wireless-G Ethernet Bridge with 5-port Switch:WEP
Dimensions (WxDxH)
- Wireless-G Ethernet Bridge:126 x 27 x 107 mm
- Wireless-G Ethernet Bridge with 5-port Switch:132 x 130 x 29 mm
Weight
- Wireless-G Ethernet Bridge:240 g
- Wireless-G Ethernet Bridge with 5-port Switch:390 g

Side by side

Differences highlightedShow differences only

Comparison of Wireless-G Ethernet Bridge, Wireless-G Ethernet Bridge with 5-port Switch
20 specifications	A Linksys Wireless-G Ethernet Bridge View product	B Linksys Wireless-G Ethernet Bridge with 5-port Switch View product
Data transmissionidentical
Maximum data transfer rate	54 Mbit/s	54 Mbit/s
Wireless LAN featuresidentical
Frequency band	2.4 GHz	2.4 GHz
Network1 differ
Networking standardsDiffers	IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u	IEEE 802.3, IEEE 802.3u, IEEE 802.11g, IEEE 802.11b, IEEE 802.1Q, IEEE 802.1d
Number of usersKnown for one	Unknown — not stated by the source	64 user(s)
Ports & interfaces1 differ
Connectivity technology	Wireless	Wireless
I/O portsDiffers	1x 10/100 Auto-Crossover (MDI/MDI-X) 1x Power	5 x 10/100 Auto MDI/MDIX
Security1 differ
Security algorithmsDiffers	WEP, WPA	WEP
Featuresidentical
LED indicatorsKnown for one	Unknown — not stated by the source	Power
System requirements2 differ
Minimum system requirementsDiffers	CD-ROM Network Adapter Ethernet (UTP CAT 5) Cabling TCP/IP per PC Internet Explorer 4.0/Netscape Navigator 4.0	- CD-ROM Drive - Ethernet Adapter - Internet Explorer 4.0, Netscape Navigator 4.0
Compatible operating systemsDiffers	Microsoft Windows 98SE, 2000, Me, XP	Microsoft Windows 98SE, Me, 2000, XP
Poweridentical
Power requirementsKnown for one	Unknown — not stated by the source	5VDC 2A
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)	10 - 85%	10 - 85%
Storage temperature (T-T)	-20 - 70 °C	-20 - 70 °C
Non-operating relative humidity (non-condensing)Known for one	Unknown — not stated by the source	5 - 90%
Storage relative humidity (H-H)Known for one	5 - 95%	Unknown — not stated by the source
Certificates1 differ
CertificationDiffers	FCC, CE	FCC Class B, CE Class B, VCCI Class B
Weight & dimensions2 differ
Dimensions (WxDxH)Differs	126 x 27 x 107 mm	132 x 130 x 29 mm
WeightDiffers	240 g	390 g
Management featuresidentical
Data link protocolsKnown for one	802.11b: CCK (11Mbps), CCK (5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps), 802.11g: OFDM (54Mbps)	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
