Product comparison · 2 bridges & repeaters

LevelOne PLI-2030 bridge/repeater 200 Mbit/s vs LevelOne WAB-3000A bridge/repeater 108 Mbit/s

9specifications compared
9differ
0identical
11known for one product only

Key differences

Maximum data transfer rate
- PLI-2030 bridge/repeater 200 Mbit/s:200 Mbit/s
- WAB-3000A bridge/repeater 108 Mbit/s:108 Mbit/s
Connectivity technology
- PLI-2030 bridge/repeater 200 Mbit/s:Wired
- WAB-3000A bridge/repeater 108 Mbit/s:Wireless
Connectivity LEDs
- PLI-2030 bridge/repeater 200 Mbit/s:Yes
- WAB-3000A bridge/repeater 108 Mbit/s:WAN, WLAN
Operating temperature (T-T)
- PLI-2030 bridge/repeater 200 Mbit/s:0 - 45 °C
- WAB-3000A bridge/repeater 108 Mbit/s:-5 - 50 °C
Operating relative humidity (H-H)
- PLI-2030 bridge/repeater 200 Mbit/s:10 - 90%
- WAB-3000A bridge/repeater 108 Mbit/s:0 - 95%
Storage temperature (T-T)
- PLI-2030 bridge/repeater 200 Mbit/s:-25 - 70 °C
- WAB-3000A bridge/repeater 108 Mbit/s:-40 - 80 °C
Certification
- PLI-2030 bridge/repeater 200 Mbit/s:FCC, CE, UL, CE LVD
- WAB-3000A bridge/repeater 108 Mbit/s:EMI/Safety: FCC Class A, CE
Dimensions (WxDxH)
- PLI-2030 bridge/repeater 200 Mbit/s:71.5 x 103 x 38 mm
- WAB-3000A bridge/repeater 108 Mbit/s:235 x 210 x 76.2 mm

Side by side

Differences highlightedShow differences only

Comparison of PLI-2030, WAB-3000A
20 specifications	A LevelOne PLI-2030 bridge/repeater 200 Mbit/s Model PLI-2030 View product	B LevelOne WAB-3000A bridge/repeater 108 Mbit/s Model WAB-3000A View product
Data transmission1 differ
Maximum data transfer rateDiffers	200 Mbit/s	108 Mbit/s
Antennaidentical
Antenna gain level (max)Known for one	Unknown — not stated by the source	5 dBi
Network1 differ
Networking standardsDiffers	IEEE 802.3, IEEE 802.3u, IEEE 802.3x	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.1Q
Cabling technologyKnown for one	10Base-T(X)	Unknown — not stated by the source
Ports & interfaces1 differ
Connectivity technologyDiffers	Wired	Wireless
I/O portsKnown for one	Unknown — not stated by the source	1 x 10/100 Mbps WAN 1 x LAN port
InterfaceKnown for one	RJ 45	Unknown — not stated by the source
Securityidentical
Security algorithmsKnown for one	Unknown — not stated by the source	WPA, WPA-PSK, WPA2
MAC address filteringKnown for one	Unknown — not stated by the source	Yes
Features1 differ
Connectivity LEDsDiffers	Yes	WAN, WLAN
Poweridentical
Power over Ethernet (PoE)Known for one	Unknown — not stated by the source	Yes
Power requirementsKnown for one	AC 100-240 VAC, 50-60 Hz	Unknown — not stated by the source
Operational conditions3 differ
Operating temperature (T-T)Differs	0 - 45 °C	-5 - 50 °C
Operating relative humidity (H-H)Differs	10 - 90%	0 - 95%
Storage temperature (T-T)Differs	-25 - 70 °C	-40 - 80 °C
Certificates1 differ
CertificationDiffers	FCC, CE, UL, CE LVD	EMI/Safety: FCC Class A, CE
Weight & dimensions1 differ
Dimensions (WxDxH)Differs	71.5 x 103 x 38 mm	235 x 210 x 76.2 mm
WeightKnown for one	Unknown — not stated by the source	2.5 kg
Wireless LAN featuresidentical
ModulationKnown for one	BPSK, QPSK	Unknown — not stated by the source
System requirementsidentical
Compatible operating systemsKnown for one	Windows 200/XP	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
