Product comparison · 2 audio mixers

Yamaha EMX5 audio mixer 12 channels Black vs Yamaha QL1 audio mixer 40 channels Black

Key differences

Channels quantity
- EMX5 audio mixer 12 channels Black:12 channels
- QL1 audio mixer 40 channels Black:40 channels
Crosstalk (1kHz)
- EMX5 audio mixer 12 channels Black:-85 dB
- QL1 audio mixer 40 channels Black:-100 dB
Power consumption (typical)
- EMX5 audio mixer 12 channels Black:42 W
- QL1 audio mixer 40 channels Black:135 W
AC input voltage
- EMX5 audio mixer 12 channels Black:100 - 240 V
- QL1 audio mixer 40 channels Black:100-240 V
Width
- EMX5 audio mixer 12 channels Black:465 mm
- QL1 audio mixer 40 channels Black:468 mm
Depth
- EMX5 audio mixer 12 channels Black:325 mm
- QL1 audio mixer 40 channels Black:562 mm
Height
- EMX5 audio mixer 12 channels Black:308 mm
- QL1 audio mixer 40 channels Black:272 mm
Weight
- EMX5 audio mixer 12 channels Black:9.5 kg
- QL1 audio mixer 40 channels Black:14.7 kg

Differences highlightedShow differences only

Comparison of EMX5, QL1
17 specifications	A Yamaha EMX5 audio mixer 12 channels Black Model EMX5 View product	B Yamaha QL1 audio mixer 40 channels Black Model QL1 View product
Audio2 differ
Channels quantityDiffers	12 channels	40 channels
Crosstalk (1kHz)Differs	-85 dB	-100 dB
Equalizeridentical
EqualizerKnown for one	Yes	Unknown — not stated by the source
Ports & interfacesidentical
AUX out portsKnown for one	2	Unknown — not stated by the source
Technical detailsidentical
Product colour	Black	Black
Video capabilityKnown for one	No	Unknown — not stated by the source
Rack mountingKnown for one	Unknown — not stated by the source	Yes
Power2 differ
Power consumption (typical)Differs	42 W	135 W
AC input voltageDiffers	100 - 240 V	100-240 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Phantom powerKnown for one	48 V	Unknown — not stated by the source
Weight & dimensions4 differ
WidthDiffers	465 mm	468 mm
DepthDiffers	325 mm	562 mm
HeightDiffers	308 mm	272 mm
WeightDiffers	9.5 kg	14.7 kg
Packaging contentidentical
Cables includedKnown for one	AC	Unknown — not stated by the source
Outputsidentical
Total Harmonic Distortion (THD)Known for one	Unknown — not stated by the source	0.05%

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
