Product comparison · 2 audio mixers

Yamaha CL5 audio mixer 80 channels 20 vs Yamaha TF5 audio mixer 48 channels 20

11specifications compared
8differ
3identical
15known for one product only

Key differences

Channels quantity
- CL5 audio mixer 80 channels 20:80 channels
- TF5 audio mixer 48 channels 20:48 channels
Supported sample rates
- CL5 audio mixer 80 channels 20:44.1,48 kHz
- TF5 audio mixer 48 channels 20:48 kHz
Product colour
- CL5 audio mixer 80 channels 20:Black
- TF5 audio mixer 48 channels 20:Black, Grey
Power consumption (typical)
- CL5 audio mixer 80 channels 20:170 W
- TF5 audio mixer 48 channels 20:120 W
Width
- CL5 audio mixer 80 channels 20:1053 mm
- TF5 audio mixer 48 channels 20:866 mm
Depth
- CL5 audio mixer 80 channels 20:667 mm
- TF5 audio mixer 48 channels 20:599 mm
Height
- CL5 audio mixer 80 channels 20:299 mm
- TF5 audio mixer 48 channels 20:225 mm
Weight
- CL5 audio mixer 80 channels 20:36 kg
- TF5 audio mixer 48 channels 20:20 kg

Side by side

Differences highlightedShow differences only

Comparison of CL5, TF5
26 specifications	A Yamaha CL5 audio mixer 80 channels 20 Model CL5 View product	B Yamaha TF5 audio mixer 48 channels 20 Model TF5 View product
Audio2 differ
Channels quantityDiffers	80 channels	48 channels
Supported sample ratesDiffers	44.1,48 kHz	48 kHz
Sample rateKnown for one	Unknown — not stated by the source	48 kHz
Frequency range	20 - 20000 Hz	20 - 20000 Hz
Crosstalk (1kHz)	-100 dB	-100 dB
Signal delay (@48kHz)Known for one	2.5 ms	Unknown — not stated by the source
Gain adjustment rangeKnown for one	-96 - 24 dB	Unknown — not stated by the source
Inputsidentical
Line-in maximum inputKnown for one	Unknown — not stated by the source	-128 dBV
Input impedanceKnown for one	Unknown — not stated by the source	600 Ω
Displayidentical
Built-in displayKnown for one	Unknown — not stated by the source	No
Equalizeridentical
EqualizerKnown for one	Unknown — not stated by the source	Yes
Ports & interfacesidentical
Omni outKnown for one	Unknown — not stated by the source	1
RJ-45 ports quantityKnown for one	1	Unknown — not stated by the source
USB 2.0 ports quantityKnown for one	1	Unknown — not stated by the source
Technical details1 differ
DJ mixerKnown for one	Unknown — not stated by the source	Yes
Rack mountingKnown for one	Unknown — not stated by the source	Yes
BacklightKnown for one	Unknown — not stated by the source	Yes
Product colourDiffers	Black	Black, Grey
Video capability	No	No
Power1 differ
Power consumption (typical)Differs	170 W	120 W
AC input voltageKnown for one	Unknown — not stated by the source	100 - 240 V
AC input frequencyKnown for one	Unknown — not stated by the source	50 - 60 Hz
Weight & dimensions4 differ
WidthDiffers	1053 mm	866 mm
DepthDiffers	667 mm	599 mm
HeightDiffers	299 mm	225 mm
WeightDiffers	36 kg	20 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
