Product comparison · 2 audio cards

Nilox PCI-AUD6 Internal 5.1 channels vs Nilox PCI-AUD8 Internal 7.1 channels

Key differences

Audio output channels
- PCI-AUD6 Internal 5.1 channels:5.1 channels
- PCI-AUD8 Internal 7.1 channels:7.1 channels
Audio quality
- PCI-AUD6 Internal 5.1 channels:16 bit
- PCI-AUD8 Internal 7.1 channels:32 bit
Audio system maximum sampling rate
- PCI-AUD6 Internal 5.1 channels:48 kHz
- PCI-AUD8 Internal 7.1 channels:45 kHz

Differences highlightedShow differences only

Comparison of PCI-AUD6, PCI-AUD8
16 specifications	A Nilox PCI-AUD6 Internal 5.1 channels Model PCI-AUD6 View product	B Nilox PCI-AUD8 Internal 7.1 channels Model PCI-AUD8 View product
Audio2 differ
Internal	Yes	Yes
Audio output channelsDiffers	5.1 channels	7.1 channels
Audio qualityDiffers	16 bit	32 bit
Line-out Signal-to-Noise Ratio (SNR)	0 dB	0 dB
Audio system direct 3D sound	Yes	Yes
Ports & interfacesidentical
Host interface	PCI	PCI
MIDI/Joystick portKnown for one	Yes	Unknown — not stated by the source
Line-inKnown for one	Yes	Unknown — not stated by the source
CD/AUX audio inKnown for one	Yes	Unknown — not stated by the source
Microphone inKnown for one	Yes	Unknown — not stated by the source
S/PDIF out portKnown for one	Unknown — not stated by the source	Yes
System requirementsidentical
Minimum processor	Pentium III	Pentium III
Other features2 differ
Package dimensions (WxDxH)	170 x 40 x 240 mm	170 x 40 x 240 mm
Compatible operating systemsDiffers	DOS, Windows 3.x, Windows 95/98/NT/2000	Win 3.1, 95, 98, 2000, XP, Vista NT4.0, Linux
Audio system maximum sampling rateDiffers	48 kHz	45 kHz
Technical detailsidentical
I/O portsKnown for one	Unknown — not stated by the source	1 x MPU-401; 1 x Dual Port game

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
