Product comparison · 2 all-in-one pcs/workstations

TERRA 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500 vs TERRA 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400

86specifications compared
15differ
71identical
30known for one product only

Key differences

Processor generation
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:Intel® Core™ i5 (14th gen)
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:12th gen Intel® Core™ i5
Processor model
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:i5-14500
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:i5-12400
Processor cores
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:14
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:6
Processor threads
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:20
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:12
Processor boost frequency
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:5 GHz
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:4.4 GHz
Efficient cores
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:8
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:0
Performance-core Max Turbo Frequency
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:5 GHz
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:4.4 GHz
Performance-core base frequency
- 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500:2.6 GHz
- 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400:2.5 GHz

Side by side

Differences highlightedShow differences only

Comparison of 1000036, 1000037
116 specifications	A TERRA 1000036 All-in-One PC/workstation Intel® Core™ i5 i5-14500 Model 1000036 View product	B TERRA 1000037 All-in-One PC/workstation Intel® Core™ i5 i5-12400 Model 1000037 View product
Displayidentical
Display diagonal	60.5 cm (23.8")	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels	1920 x 1080 pixels
Touchscreen	No	No
HD type	Full HD	Full HD
Display brightness	250 cd/m²	250 cd/m²
Panel type	LCD	LCD
Response timeKnown for one	14 ms	Unknown — not stated by the source
Contrast ratio (typical)Known for one	1300:1	Unknown — not stated by the source
Viewing angle, horizontalKnown for one	178°	Unknown — not stated by the source
Viewing angle, verticalKnown for one	178°	Unknown — not stated by the source
Processor10 differ
Processor manufacturer	Intel	Intel
Processor family	Intel® Core™ i5	Intel® Core™ i5
Processor generationDiffers	Intel® Core™ i5 (14th gen)	12th gen Intel® Core™ i5
Processor modelDiffers	i5-14500	i5-12400
Processor coresDiffers	14	6
Processor threadsDiffers	20	12
Processor boost frequencyDiffers	5 GHz	4.4 GHz
Performance cores	6	6
Efficient coresDiffers	8	0
Performance-core Max Turbo FrequencyDiffers	5 GHz	4.4 GHz
Efficient-core Max Turbo FrequencyKnown for one	3.7 GHz	Unknown — not stated by the source
Performance-core base frequencyDiffers	2.6 GHz	2.5 GHz
Efficient-core base frequencyKnown for one	1.9 GHz	Unknown — not stated by the source
Processor cacheDiffers	24 MB	18 MB
Processor cache type	Smart Cache	Smart Cache
Processor socketKnown for one	LGA 1700	Unknown — not stated by the source
Maximum turbo powerDiffers	154 W	117 W
Processor base power	65 W	65 W
Processor frequencyKnown for one	Unknown — not stated by the source	2.5 GHz
Memoryidentical
Internal memory	16 GB	16 GB
Internal memory type	DDR5-SDRAM	DDR5-SDRAM
Maximum internal memory	64 GB	64 GB
Memory slots	2	2
Memory slots typeKnown for one	SO-DIMM	Unknown — not stated by the source
Memory clock speed	5600 MHz	5600 MHz
Memory layout (slots x size)	1 x 16 GB	1 x 16 GB
Storage3 differ
Total storage capacityDiffers	1 TB	500 GB
Storage media	SSD	SSD
Total SSDs capacityDiffers	1 TB	500 GB
Number of SSDs installed	1	1
SSD capacityDiffers	1 TB	500 GB
NVMe	Yes	Yes
SSD interface	PCI Express 4.0	PCI Express 4.0
SSD form factor	M.2	M.2
RAID supportKnown for one	No	Unknown — not stated by the source
Optical drive type	No	No
Storage optionsKnown for one	2x S-ATA 6GB/s ¦ 1x M.2 type 2260/2280 (SATA & PCIe 4.0 x4 NVMe)	Unknown — not stated by the source
Graphics1 differ
Discrete graphics card	No	No
Discrete graphics card model	Not available	Not available
On-board GPU manufacturer	Intel	Intel
On-board graphics card	Yes	Yes
On-board graphics card family	Intel® UHD Graphics	Intel® UHD Graphics
On-board graphics card modelDiffers	Intel® UHD Graphics	Intel UHD Graphics 730
Audioidentical
Built-in speaker(s)	Yes	Yes
Number of speakers	2	2
RMS rated power	6 W	6 W
Cameraidentical
Built-in camera	Yes	Yes
Networkidentical
Wi-Fi	Yes	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)	Wi-Fi 6 (802.11ax)
WLAN controller manufacturer	Intel	Intel
Wi-Fi standards	Wi-Fi 6 (802.11ax)	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201	Intel Wi-Fi 6 AX201
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	100,1000 Mbit/s	100,1000 Mbit/s
Bluetooth	Yes	Yes
Bluetooth version	5.2	5.2
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	1	1
USB 2.0 ports quantity	2	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0	0
USB4 Gen 3x2 ports quantity	0	0
HDMI ports quantity	1	1
HDMI version	2.0	2.0
DisplayPorts quantity	1	1
Microphone in	Yes	Yes
Audio output	Yes	Yes
DC-in jack	Yes	Yes
Designidentical
Product colour	Black	Black
Cable lock slot	Yes	Yes
Cable lock slot type	Kensington	Kensington
Panel mounting interface	100 x 100 mm	100 x 100 mm
VESA mounting	Yes	Yes
Performanceidentical
Product type	All-in-One PC	All-in-One PC
Cooling typeKnown for one	Active	Unknown — not stated by the source
Market positioning	Business	Business
Trusted Platform Module (TPM)Known for one	Yes	Unknown — not stated by the source
Trusted Platform Module (TPM) versionKnown for one	2.0	Unknown — not stated by the source
Softwareidentical
Operating system installed	Windows 11 Pro	Windows 11 Pro
Operating system architecture	64-bit	64-bit
Power1 differ
AC adapter power	120 W	120 W
AC adapter frequencyDiffers	50/60 Hz	50 - 60 Hz
AC adapter input voltage	100 - 240 V	100 - 240 V
Power consumption (off)Known for one	0.2 W	Unknown — not stated by the source
Power consumption (standby)Known for one	1.9 W	Unknown — not stated by the source
Weight & dimensionsidentical
Width (with stand)	540 mm	540 mm
Depth (with stand)	54 mm	54 mm
Height (with stand)	520 mm	520 mm
Weight (with stand)	7.5 kg	7.5 kg
WeightKnown for one	7.5 kg	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)	5 - 35 °C	5 - 35 °C
Operating relative humidity (H-H)	10 - 75%	10 - 75%
Packaging contentidentical
AC adapter includedKnown for one	Yes	Unknown — not stated by the source
Cables includedKnown for one	AC	Unknown — not stated by the source
Quick start guideKnown for one	Yes	Unknown — not stated by the source
Other featuresidentical
Audio output channelsKnown for one	8.0 channels	Unknown — not stated by the source
Compatible operating systemsKnown for one	Windows 10, Windows 11	Unknown — not stated by the source
LocaleKnown for one	International repository	Unknown — not stated by the source
Maximum number of SMP processorsKnown for one	1	Unknown — not stated by the source
Number of processors installedKnown for one	1	Unknown — not stated by the source
Power consumption (short idle)Known for one	34.45 W	Unknown — not stated by the source
Power supplyKnown for one	120 W	Unknown — not stated by the source
Expansion slotsKnown for one	1x 2.5" SSD	Unknown — not stated by the source
Resolution descriptionKnown for one	HDMI 2.1 max. 4096 x 2160, DP 1.4 max. 4096 x 2304	Unknown — not stated by the source
Certificatesidentical
CertificationKnown for one	Unknown — not stated by the source	SMBios (DMI), EnergyStar 8.0, EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
