Product comparison · 2 all-in-one pcs/workstations

Nilox AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K vs Nilox NX21AIO2C240 Intel® Celeron® G G4900

97specifications compared
32differ
65identical
23known for one product only

Key differences

Display diagonal
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:61 cm (24")
- NX21AIO2C240 Intel® Celeron® G G4900:54.6 cm (21.5")
Display resolution
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:1920 x 1080 pixels
- NX21AIO2C240 Intel® Celeron® G G4900:1080 x 1920 pixels
Processor family
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:Intel® Core™ i5
- NX21AIO2C240 Intel® Celeron® G G4900:Intel® Celeron® G
Processor model
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:i5-9600K
- NX21AIO2C240 Intel® Celeron® G G4900:G4900
Processor cores
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:6
- NX21AIO2C240 Intel® Celeron® G G4900:2
Processor threads
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:6
- NX21AIO2C240 Intel® Celeron® G G4900:2
Processor frequency
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:3.7 GHz
- NX21AIO2C240 Intel® Celeron® G G4900:3.1 GHz
Processor cache
- AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K:9 MB
- NX21AIO2C240 Intel® Celeron® G G4900:2 MB

Side by side

Differences highlightedShow differences only

Comparison of AYNX24960, NX21AIO2C240
120 specifications	A Nilox AYNX24960 All-in-One PC/workstation Intel® Core™ i5 i5-9600K Model AYNX24960 View product	B Nilox NX21AIO2C240 Intel® Celeron® G G4900 Model NX21AIO2C240 View product
Display2 differ
Display diagonalDiffers	61 cm (24")	54.6 cm (21.5")
Display resolutionDiffers	1920 x 1080 pixels	1080 x 1920 pixels
TouchscreenKnown for one	Unknown — not stated by the source	No
HD type	HD	HD
Native aspect ratio	16:9	16:9
Display brightness	300 cd/m²	300 cd/m²
Processor11 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i5	Intel® Celeron® G
Processor modelDiffers	i5-9600K	G4900
Processor coresDiffers	6	2
Processor threadsDiffers	6	2
Processor frequencyDiffers	3.7 GHz	3.1 GHz
Processor cacheDiffers	9 MB	2 MB
Processor cache type	Smart Cache	Smart Cache
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
System bus rate	8 GT/s	8 GT/s
Thermal Design Power (TDP)Differs	95 W	54 W
Bus typeKnown for one	Unknown — not stated by the source	DMI3
Maximum number of PCI Express lanes	16	16
PCI Express configurationsDiffers	1x16, 2x8, 1x8+2x4	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0	3.0
Processor codeKnown for one	Unknown — not stated by the source	SR3W4
Processor codename	Coffee Lake	Coffee Lake
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
SteppingKnown for one	Unknown — not stated by the source	B0
Tjunction	100 °C	100 °C
Maximum internal memory supported by processorDiffers	128 GB	64 GB
Memory types supported by processor	DDR4-SDRAM	DDR4-SDRAM
Memory clock speeds supported by processorDiffers	2666 MHz	2400 MHz
Memory bandwidth supported by processor (max)Differs	41.6 GB/s	37.5 GB/s
Processor generationKnown for one	9th gen Intel® Core™ i5	Unknown — not stated by the source
Processor boost frequencyKnown for one	4.6 GHz	Unknown — not stated by the source
Memory2 differ
Internal memoryDiffers	8 GB	4 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Maximum internal memory	16 GB	16 GB
Memory slotsDiffers	1x SO-DIMM	2
Memory slots typeKnown for one	Unknown — not stated by the source	SO-DIMM
Memory clock speedKnown for one	2133 MHz	Unknown — not stated by the source
Storage1 differ
Total storage capacity	240 GB	240 GB
Storage media	SSD	SSD
SSD capacity	240 GB	240 GB
SSD interface	SATA III	SATA III
Card reader integratedDiffers	Yes	No
Total SSDs capacityKnown for one	240 GB	Unknown — not stated by the source
Number of SSDs installedKnown for one	1	Unknown — not stated by the source
Graphics3 differ
Discrete graphics card	No	No
On-board graphics card	Yes	Yes
On-board graphics card family	Intel® HD Graphics	Intel® HD Graphics
On-board graphics card modelDiffers	Intel® UHD Graphics 630	Intel® UHD Graphics 610
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)Differs	1150 MHz	1050 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card IDDiffers	0x3E98	0x3E93
On-board graphics card OpenGL version	4.5	4.5
Audioidentical
Built-in speaker(s)	Yes	Yes
Cameraidentical
Built-in camera	Yes	Yes
Networkidentical
Wi-Fi	Yes	Yes
Top Wi-Fi standard	Wi-Fi 4 (802.11n)	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Bluetooth	Yes	Yes
Ports & interfacesidentical
Thunderbolt ports quantity	0	0
HDMI ports quantity	1	1
VGA (D-Sub) ports quantity	1	1
DisplayPorts quantity	0	0
Mini DisplayPorts quantityKnown for one	Unknown — not stated by the source	0
Ethernet LAN (RJ-45) portsKnown for one	1	Unknown — not stated by the source
Headphone outputsKnown for one	1	Unknown — not stated by the source
Microphone inKnown for one	Yes	Unknown — not stated by the source
DC-in jackKnown for one	Yes	Unknown — not stated by the source
PS/2 ports quantityKnown for one	0	Unknown — not stated by the source
Design1 differ
Product colourDiffers	Black, Silver	White
Performanceidentical
Product type	All-in-One PC	All-in-One PC
Softwareidentical
Operating system installed	Windows 10	Windows 10
Operating system architecture	64-bit	64-bit
Processor special features8 differ
CPU configuration (max)	1	1
Embedded options availableDiffers	No	Yes
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt StateKnown for one	Unknown — not stated by the source	Yes
Intel Secure Key Technology versionKnown for one	Unknown — not stated by the source	1.00
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)Differs	Yes	No
Intel Stable Image Platform Program (SIPP) versionKnown for one	Unknown — not stated by the source	0.00
Intel TSX-NIDiffers	Yes	No
Intel TSX-NI versionKnown for one	Unknown — not stated by the source	0.00
Intel Trusted Execution TechnologyDiffers	Yes	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Known for one	Unknown — not stated by the source	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Secure Key	Yes	Yes
Intel® Turbo Boost TechnologyDiffers	2.0	No
Processor ARK IDDiffers	134896	129487
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction setsDiffers	SSE4.1, SSE4.2, AVX 2.0	SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specificationDiffers	PCG 2015D	PCG 2015C
Poweridentical
AC adapter powerKnown for one	Unknown — not stated by the source	90 W
Weight & dimensions4 differ
Width (with stand)Differs	540 mm	530 mm
Depth (with stand)Differs	143 mm	150 mm
Height (with stand)Differs	410 mm	400 mm
Weight (with stand)Differs	5 kg	6 kg
Packaging contentidentical
Mouse included	No	No
Other featuresidentical
Display includedKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
