Product comparison · 2 all-in-one pcs/workstations

Haier Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610 vs Haier Q8s-B206 Intel® Pentium® 2020M

118specifications compared
32differ
86identical
13known for one product only

Key differences

Display diagonal
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:50.8 cm (20")
- Q8s-B206 Intel® Pentium® 2020M:59.9 cm (23.6")
Processor family
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:Intel® Celeron® G
- Q8s-B206 Intel® Pentium® 2020M:Intel® Pentium®
Processor model
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:G1610
- Q8s-B206 Intel® Pentium® 2020M:2020M
Processor frequency
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:2.6 GHz
- Q8s-B206 Intel® Pentium® 2020M:2.4 GHz
Processor socket
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:LGA 1155 (Socket H2)
- Q8s-B206 Intel® Pentium® 2020M:PGA988
Thermal Design Power (TDP)
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:55 W
- Q8s-B206 Intel® Pentium® 2020M:35 W
CPU multiplier (bus/core ratio)
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:26
- Q8s-B206 Intel® Pentium® 2020M:24
Processor code
- Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610:SR10K
- Q8s-B206 Intel® Pentium® 2020M:SR0U1

Side by side

Differences highlightedShow differences only

Comparison of Q52-C212T, Q8s-B206
131 specifications	A Haier Q52-C212T All-in-One PC/workstation Intel® Celeron® G G1610 Model Q52-C212T View product	B Haier Q8s-B206 Intel® Pentium® 2020M Model Q8s-B206 View product
Display1 differ
Display diagonalDiffers	50.8 cm (20")	59.9 cm (23.6")
Touchscreen	No	No
LED backlight	Yes	Yes
Screen shape	Flat	Flat
Processor12 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Celeron® G	Intel® Pentium®
Processor modelDiffers	G1610	2020M
Processor cores	2	2
Processor threads	2	2
Processor frequencyDiffers	2.6 GHz	2.4 GHz
Processor cache	2 MB	2 MB
Processor cache type	Smart Cache	Smart Cache
Processor socketDiffers	LGA 1155 (Socket H2)	PGA988
System bus rate	5 GT/s	5 GT/s
64-bit computing	Yes	Yes
Thermal Design Power (TDP)Differs	55 W	35 W
Bus type	DMI	DMI
CPU multiplier (bus/core ratio)Differs	26	24
FSB Parity	No	No
PCI Express configurations	1x16, 2x8, 1x8+2x4	1x16, 2x8, 1x8+2x4
PCI Express slots version	2.0	2.0
Processor codeDiffers	SR10K	SR0U1
Processor codename	Ivy Bridge	Ivy Bridge
Processor lithography	22 nm	22 nm
Processor operating modes	64-bit	64-bit
Processor seriesDiffers	Intel Celeron Processor G1000 Series for Desktop	Intel Pentium 2000 series for Mobile
SteppingDiffers	P0	L1
Conflict-Free processor	Yes	Yes
Maximum internal memory supported by processor	32 GB	32 GB
Memory types supported by processorDiffers	DDR3-SDRAM	DDR3-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processorDiffers	1333 MHz	1333,1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s	25.6 GB/s
Memory channels supported by processor	Dual	Dual
ECC supported by processorDiffers	Yes	No
Integrated 4G WiMAXKnown for one	Unknown — not stated by the source	No
Maximum number of PCI Express lanesKnown for one	Unknown — not stated by the source	16
TjunctionKnown for one	Unknown — not stated by the source	90 °C
Memoryidentical
Internal memory	4 GB	4 GB
Internal memory type	DDR3-SDRAM	DDR3-SDRAM
Storage2 differ
Total storage capacity	500 GB	500 GB
Storage media	HDD	HDD
Number of storage drives installed	1	1
Number of HDDs installed	1	1
HDD capacity	500 GB	500 GB
HDD speedDiffers	7200 RPM	5400 RPM
Optical drive typeDiffers	DVD-RW	DVD Super Multi
Card reader integratedKnown for one	Yes	Unknown — not stated by the source
Graphics3 differ
Discrete graphics card modelDiffers	NVIDIA® GeForce® 610M	NVIDIA® GeForce® GT 740M
Discrete graphics card memoryDiffers	1 GB	2 GB
Discrete graphics memory type	GDDR3	GDDR3
On-board graphics card	Yes	Yes
On-board graphics card family	Intel® HD Graphics	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics	Intel® HD Graphics
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	650 MHz	650 MHz
On-board graphics card dynamic frequency (max)Differs	1050 MHz	1100 MHz
Audioidentical
Built-in speaker(s)	Yes	Yes
Built-in microphone	Yes	Yes
RMS rated powerKnown for one	Unknown — not stated by the source	10 W
Cameraidentical
Built-in camera	Yes	Yes
Total megapixelsKnown for one	0.3 MP	Unknown — not stated by the source
Networkidentical
Wi-Fi	Yes	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Ports & interfaces3 differ
Ethernet LAN (RJ-45) ports	1	1
USB 2.0 ports quantityDiffers	4	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantityDiffers	0	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0	0
Thunderbolt 3 ports quantity	0	0
Thunderbolt ports quantity	0	0
HDMI ports quantityDiffers	1	0
VGA (D-Sub) ports quantity	0	0
Headphone outputs	1	1
Microphone in	Yes	Yes
DC-in jack	Yes	Yes
Design1 differ
Product colourDiffers	White	Black, White
Performance1 differ
Product type	All-in-One PC	All-in-One PC
Motherboard chipsetDiffers	Intel® H61	Intel HM77 Express
Software1 differ
Operating system installedDiffers	Windows 7 Home Premium	Windows 8
Operating system architecture	64-bit	64-bit
Processor special features7 differ
CPU configuration (max)	1	1
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	No	No
Intel Demand Based Switching	No	No
Intel Dual Display Capable TechnologyDiffers	No	Yes
Intel Enhanced Halt State	Yes	Yes
Intel FDI TechnologyDiffers	No	Yes
Intel Fast Memory AccessDiffers	No	Yes
Intel Flex Memory AccessDiffers	No	Yes
Intel HD Graphics	Yes	Yes
Intel Rapid Storage Technology	No	No
Intel Secure Key Technology versionKnown for one	0.00	Unknown — not stated by the source
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No	No
Intel® AES New Instructions (Intel® AES-NI)	No	No
Intel® Anti-Theft Technology (Intel® AT)	No	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® InTru™ 3D Technology	No	No
Intel® Insider™	No	No
Intel® My WiFi Technology (Intel® MWT)Differs	No	Yes
Intel® Quick Sync Video Technology	No	No
Intel® Secure KeyKnown for one	No	Unknown — not stated by the source
Intel® Smart Cache	Yes	Yes
Intel® Turbo Boost Technology	No	No
Intel® Wireless Display (Intel® WiDi)	No	No
Processor ARK IDDiffers	71072	71142
Processor package sizeDiffers	37.5 x 37.5 mm	37.5 x 37.5 (rPGA988B)
ScalabilityKnown for one	1S	Unknown — not stated by the source
Supported instruction sets	SSE4.1, SSE4.2	SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specificationKnown for one	PCG 2011C	Unknown — not stated by the source
Graphics & IMC lithographyKnown for one	Unknown — not stated by the source	22 nm
Intel® Built-in Visuals TechnologyKnown for one	Unknown — not stated by the source	No
Packaging content1 differ
Mouse includedDiffers	Yes	No
Keyboard included	Yes	Yes
AC adapter included	Yes	Yes
Other featuresidentical
3D	No	No
Autonomy mode	No	No
Detachable display	No	No
TV tuner integratedKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
