3.5" Bay Mount Expansion Panel, 1x USB-A port, Multi-Card Reader/Writer 48-in-1, 5 Gbps (USB 3.2 Gen1 aka USB 3.0), SuperSpeed USB, Black, Three Year
Model 101967EAN 766623101967
29 specifications
- ConnectivityUSB
- Weight187 g
- ColourBlack, Grey
- InternalNo
- Output current900 mA
- Width101 mm
Overview
- Connectivity
- USB
- Weight
- 187 g
- Colour
- Black, Grey
- Internal
- No
- Output current
- 900 mA
- Width
- 101 mm
- Brand
- Manhattan
- Category
- Card Reader
- Model
- 101967
- Part number
- 101967
- EAN / UPC
- 766623101967
- Also known as
- Manhattan 3.5" Bay Mount Expansion Panel, 1x USB-A port, Multi-Card Reader/Writer 48-in-1, 5 Gbps (USB 3.2 Gen1 aka USB 3.0), SuperSpeed USB, Black, Three Year
Specifications
29 specifications in 8 groups
Performance
| Specification | Value |
|---|---|
| Compatible memory cards | MMC, MMC Mobile, MMC+, MS Micro (M2), MS PRO, MS PRO Duo, MS Pro-HG Duo, Memory Stick (MS), MicroSD (TransFlash), MiniSD, RS-MMC, SD, SDHC, SDXC, xD |
| Internal | No |
| Supported drive bays | 3.5" |
| Data transfer rate | 5000 Mbit/s |
| Product colour | Black, Grey |
| Housing material | Metal, Plastic |
| Hot-swap | Yes |
| Plug and Play | Yes |
| LED indicators | Activity, Power |
| Certification | CE, FCC, WEEE, RoHS, ISO/IEC 7816, CCID, EMV |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | USB |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| SIM card support | Yes |
| Integrated USB cable | Yes |
Power
| Specification | Value |
|---|---|
| Output current | 900 mA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 101 mm |
| Depth | 101 mm |
| Height | 25 mm |
| Weight | 187 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| Quick start guide | Yes |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows |
| Mac operating systems supported | Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 50% |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84719000 |
