HF M506 + SDHC 4GB
Model HF M506 + SDHC 4GBPart no. 6096B013EAN 8714574582658
80 specifications
- Display7.62 cm (3")
- Storage0 GB
- Weight360 g
- ColourBlack
- Total megapixels2.37 MP
- Optical zoom10x
Overview
- Display
- 7.62 cm (3")
- Storage
- 0 GB
- Weight
- 360 g
- Colour
- Black
- Total megapixels
- 2.37 MP
- Optical zoom
- 10x
- Brand
- Canon
- Category
- Camcorder
- Model
- HF M506 + SDHC 4GB
- Part number
- 6096B013
- EAN / UPC
- 8714574582658
- Also known as
- Canon LEGRIA HF M506 + SDHC 4GB Handheld camcorder 2.37 MP CMOS Full HD Black
Specifications
80 specifications in 20 groups
Image sensor
| Specification | Value |
|---|---|
| Total megapixels | 2.37 MP |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Effective megapixels (image) | 2.07 MP |
| Effective megapixels (movie) | 2.07 MP |
Lens system
| Specification | Value |
|---|---|
| Optical zoom | 10x |
| Digital zoom | 200x |
| Image stabilizer | Yes |
| Interchangeable lens | No |
| Focal length range | 6.1 - 61 mm |
| Focal length (35mm film equivalent) | 43.6 - 436 mm |
| Filter size | 43 mm |
| Image stabilizer type | Optical Image Stabilization (OIS) |
| Maximum aperture number | 3 |
| Maximum focal length (35mm film equiv) | 436 mm |
| Minimum aperture number | 1.8 |
| Minimum focal length (35mm film equiv) | 43.6 mm |
Storage
| Specification | Value |
|---|---|
| Internal storage capacity | 0 GB |
| Camcorder media type | Memory card |
| Flash memory | 4 GB |
| Compatible memory cards | SD, SDHC, SDXC |
| Maximum memory card size | 64 GB |
| Memory slots | 1 |
Focusing
| Specification | Value |
|---|---|
| Focus adjustment | Auto/Manual |
| Closest focusing distance | 0.1 m |
| Face detection | Yes |
Exposure
| Specification | Value |
|---|---|
| Light exposure modes | Auto |
| Scene modes | Beach, Fireworks, Night, Portrait, Snow, Sports, Spotlight, Sunset, Underwater |
White balance
| Specification | Value |
|---|---|
| White balance | Auto, Cloudy, Daylight, Fluorescent, Fluorescent H, Shade, Tungsten |
Flash
| Specification | Value |
|---|---|
| Built-in flash | No |
| Built-in light | No |
Shutter
| Specification | Value |
|---|---|
| Camera shutter speed | 0.0005 - 0.5 s |
Display
| Specification | Value |
|---|---|
| Display diagonal | 7.62 cm (3") |
| Built-in display | Yes |
| Display | LCD |
| Display resolution (numeric) | 230000 pixels |
| Touchscreen | Yes |
Viewfinder
| Specification | Value |
|---|---|
| Viewfinder type | Not available |
Camera
| Specification | Value |
|---|---|
| Camcorder type | Handheld camcorder |
| Minimum illumination | 1 lx |
| Back Light Compensation (BLC) | Yes |
| Image processor | DIGIC DV III |
| Progressive scan | Yes |
| 3D | No |
| Image quality adjustment | Brightness, Colour depth, Contrast, Sharpness |
| Photo effects | Fader |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Tripod mounting supported | Yes |
Video
| Specification | Value |
|---|---|
| HD type | Full HD |
| Maximum video resolution | 1920 x 1080 pixels |
| Video resolutions | 1280 x 720,1440 x 1080,1920 x 1080 |
| Video formats supported | AVCHD, MP4 |
| Supported video modes | 1080p |
| Pre-record | Yes |
| Bitrate at maximum video resolution | 24 Mbit/s |
| Capture modes | FXP, LP, MXP, SP, XP+ |
Still image
| Specification | Value |
|---|---|
| Maximum image resolution | 1920 x 1080 pixels |
| Continuous shooting mode | Yes |
Audio
| Specification | Value |
|---|---|
| Audio system | Dolby Digital 2.0 |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Component video (YPbPr/YCbCr) out | 1 |
| HDMI | Yes |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| DC-in jack | Yes |
| Headphone outputs | 1 |
| S-Video out | No |
| USB connector type | Mini-USB A, Mini-USB B |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (max) | 2.16 h |
| Battery type | BP-718 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 68 mm |
| Depth | 121 mm |
| Height | 64 mm |
| Weight | 360 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| AV output | 1 |
| Zoom capability | Yes |
