Canon XA 20 Shoulder camcorder
3.09 MP CMOS Full HD Black
Model 20Part no. 8453B008EAN 8714574605739
59 specifications
- Display8.89 cm (3.5")
- Weight765 g
- ColourBlack
- Total megapixels3.09 MP
- Optical zoom20x
- Camcorder media typeMemory card
Overview
- Display
- 8.89 cm (3.5")
- Weight
- 765 g
- Colour
- Black
- Total megapixels
- 3.09 MP
- Optical zoom
- 20x
- Camcorder media type
- Memory card
- Brand
- Canon
- Category
- Camcorder
- Model
- 20
- Part numbers
- 8453B008, 8453B003, 8453B002, 8453B009, 8453B012
- EAN / UPC
- 8714574605739, 4960999977607, 4960999977706, 8714574605722 +3 more
- Also known as
- Canon XA 20 Shoulder camcorder 3.09 MP CMOS Full HD Black
Specifications
59 specifications in 17 groups
Image sensor
| Specification | Value |
|---|---|
| Total megapixels | 3.09 MP |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.84 mm (1 / 2.84") |
| Effective megapixels (movie) | 2.91 MP |
Lens system
| Specification | Value |
|---|---|
| Optical zoom | 20x |
| Digital zoom | 400x |
| Image stabilizer | Yes |
| Focal length range | 3.67 - 73.4 mm |
| Focal length (35mm film equivalent) | 26.8 - 576 mm |
| Filter size | 58 mm |
| Image stabilizer type | Hybrid Image Stabilization (HIS) |
Storage
| Specification | Value |
|---|---|
| Camcorder media type | Memory card |
| Compatible memory cards | SD, SDHC, SDXC |
| Disc types supported | No |
| Camcorder tape type | No |
| Maximum memory card size | 128 GB |
| Memory slots | 2 |
Focusing
| Specification | Value |
|---|---|
| Focus adjustment | Auto/Manual |
White balance
| Specification | Value |
|---|---|
| White balance | Auto, Cloudy, Daylight, Fluorescent, Fluorescent H, Shade, Tungsten |
Shutter
| Specification | Value |
|---|---|
| Camera shutter speed | 1/2000 s |
Display
| Specification | Value |
|---|---|
| Display diagonal | 8.89 cm (3.5") |
| Built-in display | Yes |
| Display | LCD |
| Touchscreen | Yes |
Viewfinder
| Specification | Value |
|---|---|
| Viewfinder type | Electronic |
| Viewfinder screen size | 0.24" |
Camera
| Specification | Value |
|---|---|
| Camcorder type | Shoulder camcorder |
| Minimum illumination | 0.1 lx |
| 3D | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Video
| Specification | Value |
|---|---|
| HD type | Full HD |
| Maximum video resolution | 1920 x 1080 pixels |
| Video formats supported | H.264, MPEG4 |
| Supported video modes | 1080p, 720p |
| Analog signal format system | NTSC |
| Bitrate at maximum video resolution | 28 Mbit/s |
Audio
| Specification | Value |
|---|---|
| Audio system | Dolby Digital 5.1 |
| PCM digital audio | 16-bit/48 kHz |
| Microphone connectivity | 3.5 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI | No |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| Headphone connectivity | 3.5 mm |
| Headphone outputs | 0 |
| Microphone in | Yes |
| Mini HDMI ports quantity | 1 |
| Mini-USB 2.0 ports quantity | 1 |
| S-Video out | No |
| XLR in | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium |
| Battery voltage | 7.4 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 0 - 60% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 109 mm |
| Depth | 182 mm |
| Height | 84 mm |
| Weight | 765 g |
