Vertiv Liebert GXTRT-1000IRT2UXL uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA

Vertiv Liebert GXTRT-1000IRT2UXL uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA

900 W 6 AC outlet(s)

Model GXTRT-1000IRT2UXLEAN 767041030945

63 specifications
  • Battery9 Ah
  • Noise55 dB
  • TypeRackmount
  • Weight11 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
9 Ah
Noise
55 dB
Type
Rackmount
Weight
11 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
Vertiv
Model
GXTRT-1000IRT2UXL
Part number
GXTRT-1000IRT2UXL
EAN / UPC
767041030945
Also known as
Vertiv Liebert GXTRT-1000IRT2UXL uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 900 W 6 AC outlet(s)

Specifications

63 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Output power900 W
WaveformPure sine
Input operation voltage (min)176 V
Input operation voltage (max)288 V
Input frequency40 - 70 Hz
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output voltage regulation1%
Number of input phases1
Number of output phases1
Efficiency88%
Efficiency (On-line mode)88%
Power factor0.9
Input power factor0.9
Output power factor0.9
Emergency Power Off (EPO)No
Noise level55 dB
Power protection featuresOverload
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity6 AC outlet(s)
Number of output IEC jumpers6
USB portYes
Serial ports quantity1

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity9 Ah
Battery voltage12 V
Number of batteries supported2
Typical backup time at full load3.1 min
Typical backup time at half load9 min
Hot-swap batteryYes

Design

Form factorRackmount
Product colourBlack
Rack capacity2U
Display typeLCD

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)20 - 95%
Storage relative humidity (H-H)10 - 90%
Operating altitude0 - 2000 m

Packaging content

Rack mount kitYes
Cables includedInput power cable, Output power cable, USB cable
ManualYes
Quick installation guideYes

Certificates

Compliance certificatesRoHS
CertificationCE Mark; IEC/EN 62040-1: 2014, IEC/EN 62040-2:2006+AC:2006 Class A, EN 61000-4-5: 2005 Class 2 L-N, Class 3 L-G, ISTA 2A

Safety regulation & standards

SafetyCE

Weight & dimensions

Width438 mm
Depth310 mm
Height88 mm
Weight11 kg

Packaging data

Package width600 mm
Package depth240 mm
Package height500 mm
Package weight13.1 kg

Logistics data

Harmonized System (HS) code85078000
Shipping (inner) case width50 cm
Shipping (inner) case length60 cm
Shipping (inner) case height24 cm
Shipping (inner) case gross weight13.1 kg
