OLS6KERT5U uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA
6000 W 9 AC outlet(s)
Model OLS6KERT5UEAN 4711027791302
62 specifications
- Noise62 dB
- TypeTower
- Weight75 kg
- ColourBlack
- UPS topologyDouble-conversion (Online)
- Power plugC13 coupler
Overview
- Noise
- 62 dB
- Type
- Tower
- Weight
- 75 kg
- Colour
- Black
- UPS topology
- Double-conversion (Online)
- Power plug
- C13 coupler
- Brand
- CyberPower
- Model
- OLS6KERT5U
- Part number
- OLS6KERT5U
- EAN / UPC
- 4711027791302
- Also known as
- CyberPower OLS6KERT5U uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA 6000 W 9 AC outlet(s)
Specifications
62 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 6 kVA |
| Output power | 6000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 110 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Surge energy rating | 1335 J |
| Heat dissipation | 1777 BTU/h |
| Efficiency (ECO mode) | 98% |
| Input power factor | 0.99 |
| Output power factor | 1 |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Input current Total Harmonic Distortion (THD) | 1.5% |
| EMI/RFI noise filtering | Yes |
| Noise level | 62 dB |
| Power protection features | Overload |
| Carrying handle(s) | No |
| Audible alarm(s) | Yes |
| Audible alarm modes | Battery replacement, Fault, Overload alarm |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | C13 coupler, C19 coupler, Terminal |
| Power plug | C13 coupler |
| AC outlets quantity | 9 AC outlet(s) |
| USB port | Yes |
| RS-232 ports | 1 |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Typical backup time at full load | 5.6 min |
| Typical backup time at half load | 17.7 min |
| Battery recharge time | 4 h |
| Charging current | 4 A |
| Hot-swap battery | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Product colour | Black |
| Housing material | Metal |
| Rack capacity | 5U |
| Built-in fan | Yes |
| Display type | LCD |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 1500 m |
| Non-operating altitude | 0 - 1500 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB cable |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 433 mm |
| Depth | 661 mm |
| Height | 213.5 mm |
| Weight | 75 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 575 mm |
| Package depth | 890 mm |
| Package height | 489 mm |
| Package weight | 94 kg |
| Package type | Box |
