OL5KERTHD uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA
5000 W 6 AC outlet(s)
Model OL5KERTHDEAN 4712856275902
75 specifications
- Battery6 Ah
- Noise66 dB
- TypeRackmount/Tower
- Weight42 kg
- ColourBlack
- UPS topologyDouble-conversion (Online)
Overview
- Battery
- 6 Ah
- Noise
- 66 dB
- Type
- Rackmount/Tower
- Weight
- 42 kg
- Colour
- Black
- UPS topology
- Double-conversion (Online)
- Brand
- CyberPower
- Model
- OL5KERTHD
- Part number
- OL5KERTHD
- EAN / UPC
- 4712856275902
- Also known as
- CyberPower OL5KERTHD uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 5000 W 6 AC outlet(s)
Specifications
75 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 5000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 240 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Maximum current | 24 A |
| Surge energy rating | 2430 J |
| Response time | 0 ms |
| Heat dissipation | 1186 BTU/h |
| Efficiency (ECO mode) | 97% |
| Input power factor | 0.99 |
| Output power factor | 1 |
| Power Factor Correction (PFC) type | Active |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Total Harmonic Distortion (THD) (linear load) | 3% |
| Total Harmonic Distortion (THD) (non-linear load) | 5% |
| EMI/RFI noise filtering | Yes |
| Noise level | 66 dB |
| Surge protection | Yes |
| Power protection features | Overload |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | C13 coupler, C19 coupler, Terminal |
| Power plug | Terminal |
| AC outlets quantity | 6 AC outlet(s) |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
| Serial ports quantity | 1 |
| Emergency Power Off (EPO) connector | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 6 Ah |
| Battery voltage | 12 V |
| Number of batteries supported | 1 |
| Typical backup time at full load | 2.3 min |
| Typical backup time at half load | 6.4 min |
| Battery recharge time | 4 h |
| Hot-swap battery | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Rackmount/Tower |
| Product colour | Black |
| Housing material | Metal |
| Control type | Buttons |
| Display type | LCD |
| LED indicators | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4500 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Serial, USB cable |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, EAC, RCM, RoHS |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 433 mm |
| Depth | 720 mm |
| Height | 86.5 mm |
| Weight | 42 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 600 mm |
| Package depth | 1100 mm |
| Package height | 335 mm |
| Package weight | 52 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8504408690 |
| Country of origin | China |
Other features
| Specification | Value |
|---|---|
| Battery type | RBP0144 |
