CyberPower BR700ELCD uninterruptible power supply (UPS) Line-Interactive 0.7 kVA

CyberPower BR700ELCD uninterruptible power supply (UPS) Line-Interactive 0.7 kVA

420 W 8 AC outlet(s)

Model BR700ELCDEAN 4712856270174

57 specifications
  • TypeDesktop
  • Weight5.3 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesType F
  • Battery technologySealed Lead Acid (VRLA)
See all specifications

Overview

Type
Desktop
Weight
5.3 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
Type F
Battery technology
Sealed Lead Acid (VRLA)
Brand
CyberPower
Model
BR700ELCD
Part numbers
BR700ELCD, BR700ELCD-UK
EAN / UPC
4712856270174, 4712856270532
Also known as
CyberPower BR700ELCD uninterruptible power supply (UPS) Line-Interactive 0.7 kVA 420 W 8 AC outlet(s)

Specifications

57 specifications in 11 groups

Features

UPS topologyLine-Interactive
Output power capacity0.7 kVA
Output power420 W
WaveformSine
Input operation voltage (min)165 V
Input operation voltage (max)290 V
Input frequency50/60 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating150 J
Response time4 ms
Heat dissipation71 BTU/h
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresFax, Modem, Network, Telephone
Power protection featuresShort circuit
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Fault, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet typesType F
AC outlets quantity8 AC outlet(s)
USB portYes
USB 2.0 ports quantity1
USB port typeUSB Type-A
Modem (RJ-11) ports2
Ethernet LAN (RJ-45) ports2

Battery

Battery technologySealed Lead Acid (VRLA)
Battery voltage230 V
Number of batteries supported1
Typical backup time at full load1.5 min
Typical backup time at half load9 min
Battery recharge time8 h
Replacement battery cartridgeRBP0083

Design

Form factorDesktop
Product colourBlack
Housing materialPlastic
Cable length1.5 m
Display typeLED
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 90%
Operating altitude0 - 3000 m

Certificates

Compliance certificatesCE, EAC, RoHS

Sustainability

Sustainability complianceYes

Weight & dimensions

Width166 mm
Depth288 mm
Height118 mm
Weight5.3 kg

Packaging data

Package width158 mm
Package depth325 mm
Package height230 mm
Package weight6.05 kg

Logistics data

Harmonized System (HS) code8504408590

Other features

Number of phases1
