UPO11-1AXi 1000VA/1000W PF 1.0 Online UPS Tower, LCD UL, FCC, CE 220 Vac
Model UPO11-1AXIEAN 879071004060
69 specifications
- Battery7 Ah
- Noise50 dB
- TypeTower
- Weight14.7 kg
- ColourBlack
- UPS topologyDouble-conversion (Online)
Overview
- Battery
- 7 Ah
- Noise
- 50 dB
- Type
- Tower
- Weight
- 14.7 kg
- Colour
- Black
- UPS topology
- Double-conversion (Online)
- Brand
- CDP
- Model
- UPO11-1AXI
- Part number
- UPO11-1AXI
- EAN / UPC
- 879071004060
- Also known as
- CDP UPO11-1AXi 1000VA/1000W PF 1.0 Online UPS Tower, LCD UL, FCC, CE 220 Vac
Specifications
69 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1 kVA |
| Output power | 900 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 160 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Surge energy rating | 844 J |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency (On-line mode) | 90% |
| Efficiency (ECO mode) | 97% |
| Output power factor | 0.99 |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 4% |
| Input current Total Harmonic Distortion (THD) | 3% |
| EMI/RFI noise filtering | Yes |
| Noise level | 50 dB |
| Surge protection | Yes |
| Power protection features | Overload, Short circuit |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | NEMA 5-15R |
| Power plug | NEMA 5-15P |
| AC outlets quantity | 6 AC outlet(s) |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
| Emergency Power Off (EPO) connector | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lead-Acid |
| Battery capacity | 7 Ah |
| Battery voltage | 12 V |
| Number of batteries supported | 3 |
| Typical backup time at full load | 7 min |
| Typical backup time at half load | 15 min |
| Battery recharge time | 4 h |
| Cold start | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Product colour | Black |
| Housing material | Metal |
| Cable length | 1.5 m |
| Cooling type | Active |
| Built-in fan | Yes |
| Display type | LCD |
| LED indicators | Power, Status |
| International Protection (IP) code | IP20 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, UL, cUL, FCC, ISO |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 230 mm |
| Depth | 472 mm |
| Height | 325 mm |
| Weight | 14.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 14.2 kg |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case net weight | 14.7 kg |
| Pallet gross height | 2.17 m |
| Pallet gross length | 120 cm |
| Pallet gross weight | 712 kg |
| Pallet gross width | 100 cm |
| Master (outer) case width | 230 mm |
| Master (outer) case length | 472 mm |
| Master (outer) case height | 325 mm |
| Master (outer) case gross weight | 14.2 kg |
| Products per master (outer) case | 1 pc(s) |
