ATEN OL1000LV uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA
ATEN

OL1000LV uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA

1000 W 8 AC outlet(s)

Model OL1000LVEAN 672792009990

40 specifications
  • Battery9 Ah
  • TypeRackmount/Tower
  • Weight12.9 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesNEMA 5-15R
See all specifications

Overview

Battery
9 Ah
Type
Rackmount/Tower
Weight
12.9 kg
Colour
Black
UPS topology
Double-conversion (Online)
AC outlet types
NEMA 5-15R
Brand
ATEN
Model
OL1000LV
Part number
OL1000LV
EAN / UPC
672792009990, 4719264648007
Also known as
ATEN OL1000LV uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 1000 W 8 AC outlet(s)

Specifications

40 specifications in 7 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Output power1000 W
WaveformSine
Input operation voltage (min)80 V
Input operation voltage (max)150 V
Input frequency40 - 70 Hz
Output frequency50/60 Hz
Output voltage regulation1%
Maximum current9.3 A
Input power factor0.99
Output power factor1
Crest factor3:1
Output voltage Total Harmonic Distortion (THD)4%

Ports & interfaces

AC outlet typesNEMA 5-15R
AC outlets quantity8 AC outlet(s)
USB portYes
Serial interfaceYes

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity9 Ah
Battery voltage12 V
Number of batteries supported2
Typical backup time at full load2.95 min
Typical backup time at half load10.1 min
Battery recharge time3 h
Hot-swap batteryYes
Cold startYes

Design

Form factorRackmount/Tower
Product colourBlack
Rack capacity2U

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)20 - 90%
Storage relative humidity (H-H)20 - 90%

Packaging content

Rack mount kitYes
Cables includedRS-232, USB cable

Weight & dimensions

Width438 mm
Depth410 mm
Height88 mm
Weight12.9 kg
