APC Easy UPS On-Line, 1000VA/800W, Rackmount 2U
APC

Easy UPS On-Line, 1000VA/800W, Rackmount 2U

230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit

Model SRV1KRIEAN 731304341666

66 specifications
  • Noise50 dB
  • TypeRackmount
  • Weight11 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • AC outlet typesC13 coupler
See all specifications

Overview

Noise
50 dB
Type
Rackmount
Weight
11 kg
Colour
Black
UPS topology
Double-conversion (Online)
AC outlet types
C13 coupler
Brand
APC
Model
SRV1KRI
Part number
SRV1KRI
EAN / UPC
731304341666
Also known as
APC Easy UPS On-Line, 1000VA/800W, Rackmount 2U, 230V, 3x IEC C13 outlets, Intelligent Card Slot, LCD, W/O rail kit

Specifications

66 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Output power800 W
WaveformSine
Input operation voltage (min)160 V
Input operation voltage (max)280 V
Input frequency40/70 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output voltage regulation1%
Surge energy rating600 J
Transfer time (Line Mode to Battery Mode)0 ms
Number of input phases1
Number of output phases1
Efficiency88%
Input power factor0.95
Output power factor0.8
Crest factor3:1
ECO modeYes
Emergency Power Off (EPO)No
Output voltage Total Harmonic Distortion (THD)3%
Noise level50 dB
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Fault, Low battery alarm, Overload alarm
Auto-restartYes
Maintenance-freeYes
Socket circuit breakerYes

Ports & interfaces

AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity3 AC outlet(s)
USB portYes
USB port typeUSB Type-B
Serial interfaceYes
Serial ports quantity1
SmartSlotYes

Battery

Battery technologySealed Lead Acid (VRLA)
Battery recharge time4 h
Automatic battery testYes

Design

Form factorRackmount
Product colourBlack
Rack capacity2U
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 14763.6 m

Packaging content

Cables includedUSB cable
ManualYes

Certificates

Compliance certificatesRoHS
CertificationCE, IEC 62040-1-1, IEC 62040-1-2 REACH

Weight & dimensions

Width437 mm
Depth312 mm
Height86 mm
Weight11 kg

Packaging data

Software CDYes
Package width455 mm
Package depth551 mm
Package height218 mm
Package weight13.1 kg

Logistics data

Harmonized System (HS) code85078000

Other features

Nominal input voltage230 V
Nominal output voltage230 V
