SRV10KI uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA
10000 W
Model SRV10KIEAN 731304337935
42 specifications
- TypeTower
- Weight65 kg
- ColourBlack
- UPS topologyDouble-conversion (Online)
- AC outlet typesHard Wire 3-wire (1PH + N + G)
- Battery technologySealed Lead Acid (VRLA)
Overview
- Type
- Tower
- Weight
- 65 kg
- Colour
- Black
- UPS topology
- Double-conversion (Online)
- AC outlet types
- Hard Wire 3-wire (1PH + N + G)
- Battery technology
- Sealed Lead Acid (VRLA)
- Brand
- APC
- Model
- SRV10KI
- Part number
- SRV10KI
- EAN / UPC
- 731304337935
- Also known as
- APC SRV10KI uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
Specifications
42 specifications in 11 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 kVA |
| Output power | 10000 W |
| Waveform | Sine |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Input frequency | 40 - 70 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 600 J |
| Crest factor | 3:1 |
| Emergency Power Off (EPO) | Yes |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | Hard Wire 3-wire (1PH + N + G) |
| SmartSlot | Yes |
| SmartConnect port | No |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Product colour | Black |
| Display type | LCD |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 14763.6 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB cable |
| Management card included | No |
| Manual | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Certification | CE, IEC 62040-1-1, IEC 62040-1-2, REACH |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 190 mm |
| Depth | 447 mm |
| Height | 685 mm |
| Weight | 65 kg |
Packaging data
| Specification | Value |
|---|---|
| Software CD | Yes |
| Package width | 320 mm |
| Package depth | 580 mm |
| Package height | 910 mm |
| Package weight | 77 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85078000 |
Other features
| Specification | Value |
|---|---|
| Output voltage | 230 V |
