APC Smart-UPS On-Line SRT2200RMXLI-NC - 2200VA, 8x C13 & 2x C19, rack mount, NMC

APC Smart-UPS On-Line SRT2200RMXLI-NC - 2200VA, 8x C13 & 2x C19, rack mount, NMC

Model SRT2200RMXLI-NCEAN 731304327561

57 specifications
  • Battery367 VAh
  • Noise55 dB
  • TypeRackmount
  • Weight25 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
367 VAh
Noise
55 dB
Type
Rackmount
Weight
25 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
APC
Model
SRT2200RMXLI-NC
Part number
SRT2200RMXLI-NC
EAN / UPC
731304327561
Also known as
APC Smart-UPS On-Line SRT2200RMXLI-NC - 2200VA, 8x C13 & 2x C19, rack mount, NMC

Specifications

57 specifications in 12 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity2.2 kVA
Output power1980 W
WaveformSine
Input operation voltage (min)160 V
Input operation voltage (max)275 V
Input frequency40 - 70 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating340 J
Crest factor3:1
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)2%
Noise level55 dB
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
AC outlets quantity12 AC outlet(s)
Number of output IEC jumpers2
USB portYes
Serial interfaceYes
Serial interface typeRJ-45
Ethernet LAN (RJ-45) ports1
SmartSlotYes
SmartConnect portNo

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity367 VAh
Number of batteries supported1
Battery life (max)5 year(s)
Battery recharge time3 h

Design

Form factorRackmount
Product colourBlack
Rack capacity2U
Cable length2.44 m
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Management card includedYes

Certificates

Compliance certificatesRoHS
CertificationCE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE

Sustainability

Sustainability certificatesENERGY STAR, Green Premium

Weight & dimensions

Width432 mm
Depth584 mm
Height85 mm
Weight25 kg

Packaging data

Package width599 mm
Package depth810 mm
Package height246 mm
Package weight34 kg

Logistics data

Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)3656.79

Other features

Output voltage230 V
