SMV1000I-MSX uninterruptible power supply (UPS) Line-Interactive 1 kVA
700 W 4 AC outlet(s)
Model SMV1000I-MSX
44 specifications
- Noise45 dB
- Weight13.6 kg
- ColourBlack
- UPS topologyLine-Interactive
- Power plugC14 coupler
- Battery technologySealed Lead Acid (VRLA)
Overview
- Noise
- 45 dB
- Weight
- 13.6 kg
- Colour
- Black
- UPS topology
- Line-Interactive
- Power plug
- C14 coupler
- Battery technology
- Sealed Lead Acid (VRLA)
- Brand
- APC
- Model
- SMV1000I-MSX
- Part number
- SMV1000I-MSX
- Also known as
- APC SMV1000I-MSX uninterruptible power supply (UPS) Line-Interactive 1 kVA 700 W 4 AC outlet(s)
Specifications
44 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Line-Interactive |
| Output power capacity | 1 kVA |
| Output power | 700 W |
| Waveform | Sine |
| Input operation voltage (min) | 165 V |
| Input operation voltage (max) | 290 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 230 V |
| Output operation voltage (max) | 230 V |
| Output frequency | 50/60 Hz |
| Response time | 6 ms |
| Crest factor | 3:1 |
| Noise level | 45 dB |
| Surge protection | Yes |
| Audible alarm(s) | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Power plug | C14 coupler |
| AC outlets quantity | 4 AC outlet(s) |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 12 V |
| Battery life (max) | 5 year(s) |
| Battery recharge time | 4 h |
| Cold start | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Display type | LCD |
| LED indicators | Yes |
| International Protection (IP) code | IP20 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Certificates
| Specification | Value |
|---|---|
| Certification | CE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 410 mm |
| Height | 220 mm |
| Weight | 13.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 272 mm |
| Package depth | 508 mm |
| Package height | 339 mm |
| Package weight | 16.6 kg |
